| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | VE5245 | PRIMARY ACTUATOR ASSM | ||
| 2 | VE5249 | TIE ROD ASSM | ||
| 2 | VE5248 | ACTUATOR BODY KIT | ||
| 3 | VE5264 | BODY, ACTUATOR | ||
| 4 | VE5265 | O-RING | ||
| 5 | VE2780 | SEAL, WIPER | ||
| 6 | VE2777 | RING, GLYD | ||
| 7 | VE5253 | O-RING | ||
| 8 | VE5246 | KIT, SHIM | ||
| 9 | VE5247 | PISTON | ||
| 10 | VE6902 | HARDWARE KIT | ||
| 11 | VE6900 | BODY, TANK | ||
| 12 | VE5262 | SHIM KIT | ||
| 13 | SPRING KIT | |||
| 14 | VE6901 | REGULATOR SET | ||
| 14 | VE6327 | GENERAL SEAL KIT |
