| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | EJ5624 | COVER | ||
| 2 | SL6447 | GROMMET | ||
| 3 | EJ5625 | COVER | ||
| 4 | CH4440 | CABLE, RED (PVC) | ||
| 5 | PC1000 | MOUNT, RUBBER | ||
| 6 | HA2365 | HOSE | ||
| 7 | WB0456 | FITTING, STRAIGHT | ||
| 8 | EK5343 | HARNESS, PRE LUBE | ||
| 9 | 677161R94 | SENDER, PRESSURE | ||
| 10 | SG3290 | SWITCH, PRESSURE | ||
| 11 | VZ0589 | SWITCH, PRESSURE | ||
| 12 | CH4315 | CABLE, BLACK (PVC) | ||
| 13 | C5768 | PLUG, PIPE 1/8" | ||
| 14 | EL8653 | LINK, FUSABLE | ||
| 15 | EJ5622 | BRACKET | ||
| 16 | WB3093 | CLAMP - 1" | ||
| 17 | CH4060 | CABLE, BLACK | ||
| 18 | WB1304 | CLAMP - 5/8" | ||
| 19 | MM0178 | NUT - M10 - 1.50 | ||
| 20 | MM0471 | LOCKWASHER - M10 | ||
| 21 | TC1234 | CAPSCREW 3/8" - 16NC X 3/4" | ||
| 22 | TR4436 | FLAT WASHER - 3/8" | ||
| 23 | TC1231 | LOCKWASHER - 3/8" | ||
| 24 | CH4115 | CABLE, BLACK | ||
| 25 | TD1548 | CAPSCREW 1/4" - 20NC X 5/8" | ||
| 26 | C1546 | FLAT WASHER - 1/4" | ||
| 27 | 0803804030 | CAP | ||
| 28 | C0312 | LOCKWASHER - 3/8" | ||
| 29 | C1521 | NUT - 3/8" - 16NC | ||
| 30 | WA0720 | FLAT WASHER - 3/8" | ||
| 31 | BF4994 | STARTER ASSEMBLY (NO PRELUBE) | ||
| 31 | 09842A0481 | DECAL, JUMP START WARNING |
