| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 04434-52110 | Clip | 1001- | |
| 2 | 07095-20314 | Cushion | 1001- | |
| 3 | 01010-81020 | Bolt | 1001- | |
| 4 | 01643-31032 | Washer | 1001- | |
| 5 | 08038-02027 | Cap | 1001- | |
| 6 | 155-61-15350 | Clip | 1001- | |
| 7 | 22M-62-13660 | Cushion | 1001- | |
| 8 | 04434-53411 | Clip | 1001- | |
| 9 | 01010-81020 | Bolt | 1001- | |
| 10 | 01643-31032 | Washer | 1001- | |
| 11 | 04434-52511 | Clip | 1001- | |
| 12 | 07095-20318 | Cushion | 1001- | |
| 13 | 01010-81020 | Bolt | 1001- | |
| 14 | 01643-31032 | Washer | 1001- | |
| 15 | 04434-51810 | Clip | 1001- | |
| 16 | 01010-81020 | Bolt | 1001- | |
| 17 | 01643-31032 | Washer | 1001- | |
| 18 | 08028-ED040 | Cable, Ground | 1001- | |
| 19 | 01010-81020 | Bolt | 1001- | |
| 20 | 01643-31032 | Washer | 1001- | |
| 21 | 04434-53411 | Clip | 1001- | |
| 22 | 07095-20627 | Cushion | 1001- | |
| 23 | 01010-81020 | Bolt | 1001- | |
| 24 | 01643-31032 | Washer | 1001- | |
| 25 | 04434-52511 | Clip | 1001- | |
| 26 | 07095-20318 | Cushion | 1001- | |
| 27 | 01010-81020 | Bolt | 1001- | |
| 28 | 01643-31032 | Washer | 1001- | |
| 29 | (14X-06-61111) | Wiring Harness | - | |
| (14X-06-61111) | Wiring Harness | - |
