Item | Part No. | Part Name | Qty | Serial No. |
1 | 381-897072-3 | LAMP ASS'Y,FRONT | 10001- | |
2 | 381-985652-1 | BULB | 10001- | |
3 | 385-11067683 | BRACKET,L.H. | 10001- | |
4 | 385-11067693 | BRACKET,R.H. | 10001- | |
5 | 382-024864-1 | BOLT | 10001- | |
6 | 382-025546-1 | WASHER | 10001- | |
7 | 382-025526-1 | NUT | 10001- | |
8 | 08086-10000 | SWITCH,KEY | 10163- | |
08086-00000 | SWITCH,KEY | 10001-10162 | ||
9 | 08061-50010 | SWITCH,LIGHT | 10001- | |
10 | 381-988678-2 | SWITCH,LOW PRESSURE | 10262- | |
\0\381-988678-1 | SWITCH,LOW PRESSURE | 10001-10261 | ||
11 | 385-10336391 | SUPPORT | 10328- | |
385-11065551 | HOLDER | 10001-10327 | ||
12 | 382-025752-1 | BOLT | 10001- | |
13 | 382-025532-1 | WASHER | 10001- | |
14 | 382-025519-1 | NUT | 10001- | |
15 | 385-10328371 | BREAKER¤ 20A | 10328- | |
381-714250-1 | BREAKER¤ 20A | 10001-10327 | ||
16 | 385-10328361 | BREAKER¤ 15A | 10328- | |
381-714249-1 | BREAKER¤ 15A | 10001-10327 | ||
17 | 385-10328351 | BREAKER¤ 10A | 10328- | |
381-714248-1 | BREAKER¤ 10A | 10001-10327 | ||
18 | 385-11064601 | BAR | 10001- | |
19 | 384-0131015 | WASHER | 10328- | |
384-0120217 | WASHER | 10001-10327 | ||
20 | 384-0120622 | NUT | 10328- | |
384-0120614 | NUT | 10001-10327 | ||
21 | 385-11065491 | DIODE¤ 2A | 10001-10327 | |
22 | 385-10000992 | SWITCH,PARKING BRAKE | 10001- | |
\0\385-10000991 | SWITCH,PARKING BRAKE | 10001-10261 | ||
23 | 08061-30020 | SWITCH,WORKING | 10001- | |
24 | 08061-30070 | SWITCH,THERMOSTART | 10001- | |
25 | 381-971441-1 | BUZZER | 10001- | |
26 | 384-0444148 | TEE | 10001- | |
27 | 380-117383-1 | ELBOW | 10001- | |
28 | 381-975189-2 | SWITCH,STOP | .- | |
\0\381-975189-1 | SWITCH,STOP | 10001-. | ||
29 | 385-11224771 | SWITCH,TRANSMISSION CUT OFF | 10001-10327 | |
30 | 385-10210442 | SWITCH,BACK LAMP | 10328- | |
385-10210741 | PLUG | 10001-10327 | ||
31 | 07002-01623 | O-RING | 10001- | |
32 | 08147-22400 | LAMP,PILOT | 10001- | |
33 | 08111-02430 | BULB¤ 3W | 10001- | |
34 | 08130-62400 | LAMP ASS'Y,TURN SIGNAL¤ L.H. | 10001- | |
08130-82400 | LAMP ASS'Y,TURN SIGNAL¤ R.H. | 10001- | ||
35 | 381-980950-1 | LENS | 10001- | |
36 | 08105-12420 | BULB¤ 25W | 10001- | |
37 | 08110-12410 | BULB¤ 12W | 10001- | |
38 | 08147-22401 | LAMP | 10001- | |
39 | 08111-02430 | BULB¤ 3W | 10001- | |
40 | 08075-60000 | SWITCH,TURN | 10001- | |
41 | 08077-32400 | FLASHER | 10001- | |
42 | 382-025653-1 | BOLT | 10001- | |
43 | 382-025533-1 | WASHER | 10328- | |
382-025533-1 | WASHER | 10001-10327 | ||
44 | 382-025520-1 | NUT | 10328- | |
382-025520-1 | NUT | 10001-10327 | ||
45 | 385-10241161 | SIGNAL,HEATER | 10001- | |
46 | 385-10391161 | SWITCH,BRAKE WARNING | 10001- | |
47 | 382-025228-1 | NUT | 10328- | |
48 | 382-027328-1 | BOLT | 10328- | |
49 | 384-0131015 | WASHER | 10328- | |
50 | 385-10336381 | HOLDER | 10328- | |
51 | 384-0120622 | NUT | 10328- | |
52 | 385-10336081 | DIODE¤ 1.1A | 10328- | |
53 | 385-10264021 | RELAY | 10328- |
