| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 385-10246061 | WIRING HARNESS | 10439- | |
| 2 | 385-10366641 | WIRING HARNESS | 10709- | |
| 385-10302341 | WIRING HARNESS | 10547-10708 | ||
| 385-10231432 | WIRING HARNESS | 10439-10546 | ||
| 3 | 385-10152782 | WIRING HARNESS | 10331- | |
| 4 | 385-10152792 | WIRING HARNESS | 10547- | |
| 385-10231441 | WIRING HARNESS | 10331-10546 | ||
| 5 | 385-10293541 | WIRING HARNESS | 10511- | |
| 385-10152802 | WIRING HARNESS | 10439-10510 | ||
| 6 | 08038-00519 | CAP | 10001- | |
| 7 | 381-970708-1 | CAP | 10001- | |
| 8 | 380-129668-1 | CLIP | 10331- | |
| 9 | 381-970088-1 | PLUG | 10001- | |
| 10 | 385-10152731 | GROMMET | 10001- | |
| 11 | 381-299404-1 | CLIP | 10511- | |
| 381-299404-1 | CLIP | 10001-10510 | ||
| 12 | 01010-50812 | BOLT | 10511- | |
| 01010-50812 | BOLT | 10115-10510 | ||
| 13 | 01643-30823 | WASHER | 10001- | |
| 14 | 01010-50820 | BOLT | 10511- | |
| 01010-50820 | BOLT | 10001-10510 | ||
| 15 | 01580-10806 | NUT | 10001-10510 | |
| 16 | 382-129083-1 | CLAMP | 10001- | |
| 17 | 01010-50812 | BOLT | 10151- | |
| 18 | 01643-30823 | WASHER | 10151- | |
| 19 | 385-10005701 | CLIP | 10001- | |
| 20 | 381-976197-1 | STRAP | 10439- | |
| 21 | 381-406381-1 | CLAMP | 10001- | |
| 22 | 01010-51025 | BOLT | 10001- | |
| 23 | 01643-31032 | WASHER | 10001- | |
| 24 | 01580-11008 | NUT | 10001- | |
| 25 | 381-299567-1 | CLIP | 10511- | |
| 381-299566-1 | CLAMP | 10001-10510 | ||
| 26 | 385-10293551 | SUPPORT | 10511- | |
| 27 | 01010-50820 | BOLT | 10511- | |
| 28 | 381-976195-1 | STRAP | 10487- | |
| 29 | (385-10245851) | CABLE,SPEEDOMETER (SEE FIG.155A) | 10439- |
