| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 273-06-61430 | HARNESS | 31001- | |
| 2 | 237-06-15120 | SENSOR,OIL TEMPERATURE | 31001- | |
| 3 | 273-06-61450 | HARNESS | 31001- | |
| 08020-00000 | DIODE | 31001- | ||
| 273-06-61250 | FUSIBLE LINK | 31001- | ||
| 20Y-06-15150 | FUSIBLE LINK | 31001- | ||
| 4 | 600-815-8930 | SWITCH,STARTER RELAY | 31001- | |
| (\2\203-06-59320) | SWITCH,STARTER RELAY | (31001-31007) | ||
| 5 | 01010-80816 | BOLT | 31001- | |
| 6 | 01643-30823 | WASHER | 31001- | |
| 7 | 600-815-2170 | SWITCH | 31001- | |
| 8 | 01010-80612 | BOLT | 31001- | |
| 9 | 01643-30623 | WASHER | 31001- | |
| 10 | 08088-30000 | SWITCH,BATTERY RELAY | 31001- | |
| 11 | 01010-80825 | BOLT | 31001- | |
| 12 | 01643-30823 | WASHER | 31001- | |
| 13 | 273-06-61220 | HARNESS | 31001- | |
| 14 | 01010-80816 | BOLT | 31001- | |
| 15 | 01643-30823 | WASHER | 31001- | |
| 16 | 08038-00519 | CAP | 31001- | |
| 17 | 08053-00910 | CLIP | 31001- | |
| 18 | 01010-81016 | BOLT | 31001- | |
| 19 | 01643-31032 | WASHER | 31001- | |
| 20 | 273-06-65251 | BRACKET | 31001- | |
| 21 | 01010-81220 | BOLT | 31001- | |
| 22 | 01643-31232 | WASHER | 31001- | |
| 23 | 01010-80612 | BOLT | 31001- | |
| 24 | 01643-30623 | WASHER | 31001- | |
| 25 | 08036-02514 | CLIP | 31001- | |
| 26 | 01010-81016 | BOLT | 31001- | |
| 27 | 01643-31032 | WASHER | 31001- |
