| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 20T-06-71213 | WIRING HARNESS | 6471- | |
| 1 | 20T-06-71212 | WIRING HARNESS | 1001-6470 | |
| 1 | 203-06-57241 | FUSIBLE LINK | 1001- | |
| 1 | 08020-00000 | DIODE | 6471- | |
| 2 | 08053-01512 | CLIP | 1001- | |
| 3 | 04435-51910 | CLIP | 1001- | |
| 4 | 08036-01414 | CLIP | 1001- | |
| 5 | 08036-21414 | CLIP | 1001- | |
| 6 | 20T-06-71580 | BRACKET | 1001- | |
| 7 | 08036-02514 | CLIP | 1001- | |
| 8 | 01010-51020 | BOLT | 1001- | |
| 9 | 01643-31032 | WASHER | 1001- | |
| 10 | 08038-10525 | CAP | 1001- | |
| 11 | 08038-10519 | CAP | 1001- | |
| 12 | 08034-00519 | BAND | 1001- | |
| 13 | 416-06-11310 | GROMMET | 1001- | |
| 14 | 08037-01610 | GROMMET | 1001- | |
| 15 | 08160-61200 | HORN | 1001- | |
| 16 | 01010-50816 | BOLT | 1001- | |
| 17 | 01643-30823 | WASHER | 1001- | |
| 18 | (20T-06-71381) | SENSOR,FUEL LEVEL(SEE FIG.D0100-01A0) | 1001- | |
| 19 | 7861-92-3320 | SENSOR,ENGINE WATER TEMP. | 1001- | |
| 20 | 515-35-13930 | CLIP | 1001- | |
| 21 | 01010-50816 | BOLT | 1001- | |
| 22 | 01643-30823 | WASHER | 1001- | |
| 23 | 20T-06-71240 | CABLE | 1001- | |
| 24 | 20S-06-13230 | TERMINAL COVER | 1001- | |
| 25 | 08028-42025 | CABLE | 1001- | |
| 26 | 01010-51020 | BOLT | 1001- | |
| 27 | 01643-31032 | WASHER | 1001- | |
| 28 | 20R-06-11240 | WIRE | 1001- | |
| 29 | 08036-01414 | CLIP | 1001- | |
| 30 | 362-60-12210 | SPACER | 1001- | |
| 31 | 01010-51020 | BOLT | 7275- | |
| 31 | 01010-51030 | BOLT | 1001-7274 | |
| 32 | 01010-51020 | BOLT | 1001- | |
| 33 | 01643-31032 | WASHER | 1001- |
