| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 424-06-12214 | WIRE ASS'Y | 10253-19999 | |
| 1 | 424-06-12213 | WIRE ASS'Y | 10001-10252 | |
| 1 | 421-06-11970 | DIODE | 10253-19999 | |
| 1 | 421-06-11970 | DIODE | 10001-10252 | |
| 2 | 424-06-12151 | WIRE ASS'Y | 10001-19999 | |
| 2 | 421-06-11970 | DIODE | 10001-19999 | |
| 3 | (7819-11-2310) | SENSOR,SPEED | 10001-@ | |
| 4 | 426-06-11370 | NUT | 10001-19999 | |
| 5 | (7861-91-3310) | SENSOR,OIL TEMPERATURE | 10001-@ | |
| 6 | 424-06-12630 | BRACKET | 10001-19999 | |
| 7 | 424-06-12620 | PLATE | 10001-@ | |
| 8 | 421-06-12910 | CLIP | 10001-19999 | |
| 9 | 283-06-17120 | CLIP | 10001-19999 | |
| 10 | 421-06-12610 | CLIP | 10001-19999 | |
| 11 | 01220-40608 | SCREW | 10001-19999 | |
| 12 | 01641-20608 | WASHER | 10001-19999 | |
| 13 | 423-06-12610 | BRACKET | 10001-19999 | |
| 14 | 424-06-12260 | BRACKET | 10001-19999 | |
| 15 | 01010-51225 | BOLT | 10001-19999 | |
| 16 | 01643-31232 | WASHER | 10001-19999 | |
| 17 | 424-06-12160 | WIRE ASS'Y | 10001-19999 | |
| 18 | 424-06-12811 | WIRE ASS'Y | 10001-19999 | |
| 19 | 424-06-12550 | WIRE | 10001-19999 | |
| 20 | 01010-51016 | BOLT | 10001-19999 | |
| 21 | 01643-31032 | WASHER | 10001-19999 | |
| 22 | 08036-03014 | CLIP | 10001-19999 | |
| 23 | 01010-51220 | BOLT | 10001-19999 | |
| 24 | 01643-31232 | WASHER | 10001-19999 | |
| 25 | 08036-01814 | CLIP | 10001-19999 | |
| 26 | 08036-11210 | CLIP | 10001-19999 | |
| 27 | 08034-00823 | BAND | 10001-19999 | |
| 28 | 08036-11214 | CLIP | 10001-19999 | |
| 29 | 08034-00536 | BAND | 10001-19999 |
