| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 426-06-12315 | WIRE ASS'Y | 11326- | |
| 1 | \0\426-06-12314 | WIRE ASS'Y | 11110-11319 | |
| 1 | \0\426-06-12313 | WIRE ASS'Y | 10881-11106 | |
| 1 | 426-06-12312 | WIRE ASS'Y | 10001-10872 | |
| 2 | 426-06-12162 | WIRE ASS'Y | 11326- | |
| 2 | \0\426-06-12161 | WIRE ASS'Y | 11110-11319 | |
| 2 | \0\426-06-12160 | WIRE ASS'Y | 10001-11106 | |
| 3 | 426-06-12810 | COVER | 10001-10300 | |
| 4 | 426-06-12820 | COVER | 10001-10300 | |
| 5 | 01010-81020 | BOLT | 10001- | |
| 6 | 01643-31032 | WASHER | 10001- | |
| 7 | 423-06-12640 | CLIP | 10001- | |
| 8 | 08035-01514 | CLIP | 10001- | |
| 9 | 01010-81220 | BOLT | 10001- | |
| 10 | 01643-31232 | WASHER | 10001- | |
| 11 | 01010-81020 | BOLT | 10001- | |
| 12 | 01643-31032 | WASHER | 10001- | |
| 13 | 08052-01711 | CLIP | 10001- | |
| 14 | 01220-40608 | SCREW | 10001- | |
| 15 | 01641-20608 | WASHER | 10001- | |
| 16 | 424-06-12720 | CLIP | 10001- | |
| 17 | 424-06-12710 | CLIP | 10001- | |
| 18 | 419-09-11160 | CLIP | 10301- | |
| 18 | \0\425-70-13120 | CLIP | 10001-10300 | |
| 19 | 426-35-11250 | CLIP | 10001- | |
| 20 | 08036-01414 | CLIP | 10001- | |
| 21 | 08035-03014 | CLIP | 10001- | |
| 22 | 01010-81020 | BOLT | 10001- | |
| 23 | 01643-31032 | WASHER | 10001- | |
| 24 | 08052-01711 | CLIP | 10001- | |
| 25 | 01220-40608 | SCREW | 10001- | |
| 26 | 01641-20608 | WASHER | 10001- | |
| 27 | 426-09-11220 | GROMMET | 10999- | |
| 27 | 426-09-11220 | GROMMET | 10001-10998 | |
| 28 | 426-09-11210 | GROMMET | 10001- | |
| 29 | 04434-51010 | CLIP | 10999- | |
| 30 | 01435-01016 | BOLT | 10999- |
