| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 424-06-12314 | WIRE ASS'Y | 20001- | |
| 1 | 421-06-11970 | DIODE | 20001- | |
| 2 | 08052-02711 | CLIP | 20001- | |
| 3 | 08052-01711 | CLIP | 20001- | |
| 4 | 01220-40608 | SCREW | 20001- | |
| 5 | 01641-20608 | WASHER | 20001- | |
| 6 | 08036-03014 | CLIP | 20108- | |
| 6 | 08036-01814 | CLIP | 20001-20107 | |
| 6A | 175-06-25150 | CLIP | 20108- | |
| 7 | 01435-01020 | BOLT | 20006- | |
| 7 | 01010-51016 | BOLT | 20001-20005 | |
| 8 | 01643-31032 | WASHER | 20001-20005 | |
| 9 | 01584-01008 | NUT | 20006- | |
| 10 | 08036-01814 | CLIP | 20001- | |
| 11 | 08036-01014 | CLIP | 20001- | |
| 12 | 01435-01016 | BOLT | 20001- | |
| 13 | 424-06-12910 | GROMMET | 20001- | |
| 14 | 08034-00823 | BAND | 20001- | |
| 15 | 08034-00876 | BAND | 20001- | |
| 16 | 08036-00814 | CLIP | 20001- | |
| 17 | 01435-01016 | BOLT | 20001- |
