| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 363-06-37340 | WIRING HARNESS | 19001- | |
| 363-U15-3610 | WIRING HARNESS | 19001- | ||
| 363-06-37530 | WIRING HARNESS | 19001- | ||
| 2 | 08053-01510 | CLIP | 19001- | |
| 3 | 01435-01016 | BOLT | 19001- | |
| 4 | 04434-51010 | CLIP | 19001- | |
| 5 | 04434-51410 | CLIP | 19001- | |
| 6 | 08036-11210 | CLIP | 19001- | |
| 7 | 363-06-37130 | WIRING HARNESS | 19001- | |
| 8 | 23S-06-25151 | FUSE¤ 65A | 19001- | |
| 9 | 01580-10605 | NUT | 19001- | |
| 10 | 01641-20608 | WASHER | 19001- | |
| 11 | 04434-50608 | CLIP | 19001- | |
| 12 | 01580-10806 | NUT | 19001- | |
| 13 | 01641-20812 | WASHER | 19001- | |
| 14 | 04434-51510 | CLIP | 19001- | |
| 15 | 01435-01016 | BOLT | 19001- | |
| 16 | 209-979-6220 | BRACKET | 19001- | |
| 17 | 01435-01016 | BOLT | 19001- | |
| 18 | 04434-52511 | CLIP | 19001- | |
| 19 | 363-06-36120 | BRACKET | 19001- | |
| 20 | 04434-51710 | CLIP | 19001- | |
| 21 | 08053-01510 | CLIP | 19001- | |
| 22 | 04435-51710 | CLIP | 19001- | |
| 23 | 07095-20211 | CUSHION | 19001- | |
| 24 | 01010-81016 | BOLT | 19001- | |
| 25 | 01643-31032 | WASHER | 19001- | |
| 26 | 6152-51-5520 | SPACER | 19001- | |
| 27 | 01010-81070 | BOLT | 19001- | |
| 28 | 01643-31032 | WASHER | 19001- | |
| 29 | 04434-53411 | CLIP | 19001- | |
| 30 | 07095-00423 | CUSHION | 19001- | |
| 31 | 42A-06-22110 | WIRING HARNESS | 19001- | |
| 32 | 08038-42009 | CAP,+ | 19001- | |
| 33 | 04434-52512 | CLIP | 19001- | |
| 34 | 07095-20318 | CUSHION | 19001- | |
| 35 | 363-06-32160 | WIRE | 19001- | |
| 36 | 08038-22009 | CAP,- | 19001- | |
| 37 | 01435-01016 | BOLT | 19001- | |
| 38 | 419-06-12450 | WIRE | 19001- | |
| 39 | 01435-01016 | BOLT | 19001- | |
| 40 | 363-06-32190 | WIRING HARNESS | 19001- | |
| 41 | 08034-20519 | BAND | 19001- | |
| 42 | 01435-00612 | BOLT | 19001- | |
| 43 | 01643-30823 | WASHER | 19001- |
