| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 02762-00525 | HOSE | 3001- | |
| 2 | 02765-00423 | HOSE | 3001- | |
| 3 | 04434-53212 | CLIP | 3001- | |
| 4 | 07095-20522 | CUSHION | 3001- | |
| 5 | 04434-52711 | CLIP | 3001- | |
| 6 | 07095-20420 | CUSHION | 3001- | |
| 7 | 01010-81050 | BOLT | 3001- | |
| 8 | 01643-31032 | WASHER | 3001- | |
| 9 | 417-54-13470 | SPACER | 3001- | |
| 10 | 256-40-11610 | PLATE | 3001- | |
| 11 | 07283-34949 | CLIP | 3001- | |
| 12 | 01597-01009 | NUT | 3001- | |
| 13 | 01643-31032 | WASHER | 3001- | |
| 14 | 04434-52711 | CLIP | 3001- | |
| 15 | 07095-20420 | CUSHION | 3001- | |
| 16 | 04434-52711 | CLIP | 3001- | |
| 17 | 07095-20420 | CUSHION | 3001- | |
| 18 | 04434-53212 | CLIP | 3001- | |
| 19 | 07095-20522 | CUSHION | 3001- | |
| 20 | 01010-81016 | BOLT | 3001- | |
| 21 | 01643-31032 | WASHER | 3001- | |
| 22 | 04434-53212 | CLIP | 3001- | |
| 23 | 07095-20522 | CUSHION | 3001- | |
| 24 | 281-04-15540 | SPIRAL TUBE | 3001- | |
| 25 | 569-06-61980 | CLIP | 3012- | |
| 26 | 07095-20522 | CUSHION | 3012- |
