| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 427-87-15351 | TUBE | 10001- | |
| 2 | 07000-F2060 | O-RING | 10054- | |
| \0\07000-02060 | O-RING | 10001-10053 | ||
| 3 | 07372-21240 | BOLT | 10001- | |
| 4 | 01643-51232 | WASHER | 10001- | |
| 5 | 427-87-15431 | PLATE | 10052- | |
| 427-87-15430 | PLATE | 10001-10051 | ||
| 6 | 01435-01020 | BOLT | 10501- | |
| 01010-51025 | BOLT | 10001-10499 | ||
| 7 | 01643-31032 | WASHER | 10001-10499 | |
| 8 | 07283-36155 | CLIP | 10001- | |
| 9 | 01643-31032 | WASHER | 10001- | |
| 10 | 01597-01009 | NUT | 10001- | |
| 11 | 07260-05818 | HOSE | 10001- | |
| 12 | 07281-00909 | CLAMP | 10001- | |
| 13 | 427-87-15260 | TUBE | 10001- | |
| 14 | 07000-F3048 | O-RING | 10054- | |
| \0\07000-03048 | O-RING | 10001-10053 | ||
| 15 | 01435-01280 | BOLT | 10501- | |
| 01010-51280 | BOLT | 10001-10499 | ||
| 16 | 01643-31232 | WASHER | 10001-10499 | |
| 17 | 427-87-15151 | BRACKET | 10052- | |
| 427-87-15150 | BRACKET | 10001-10051 | ||
| 18 | 01010-81230 | BOLT | 10001- | |
| 19 | 01643-31232 | WASHER | 10001- | |
| 20 | (426-875-1100) | VALVE ASS'Y,(SEE FIG.4811) | 10001- | |
| 21 | 07040-12012 | PLUG | 10001- | |
| 22 | 07002-22034 | O-RING | 10054- | |
| \0\07002-02034 | O-RING | 10001-10053 | ||
| 23 | 01011-81025 | BOLT | 10001- | |
| 24 | 01643-31032 | WASHER | 10001- | |
| 25 | 427-87-15341 | TUBE | 10001- | |
| 26 | 07000-F3048 | O-RING | 10054- | |
| \0\07000-03048 | O-RING | 10001-10053 | ||
| 27 | 07372-21245 | BOLT | 10001- | |
| 28 | 01643-51232 | WASHER | 10001- | |
| 29 | 427-87-15331 | PLATE | 10001- | |
| 30 | 07283-34957 | CLIP | 10001- | |
| 31 | 07283-54959 | SEAT | 10001- | |
| 32 | 01643-31032 | WASHER | 10001- | |
| 33 | 01597-01009 | NUT | 10001- | |
| 34 | 07260-24722 | HOSE | 10001- | |
| 35 | 07281-00709 | CLAMP | 10001- | |
| 36 | 427-87-15230 | TUBE | 10001- | |
| 37 | 07000-F3048 | O-RING | 10054- | |
| \0\07000-03048 | O-RING | 10001-10053 | ||
| 38 | 07372-21245 | BOLT | 10001- | |
| 39 | 01643-51232 | WASHER | 10001- | |
| 40 | 07236-10210 | ELBOW | 10001- | |
| 41 | 07002-21423 | O-RING | 10054- | |
| \0\07002-11423 | O-RING | 10001-10053 | ||
| 42 | 07096-00203 | HOSE | 10001- | |
| 43 | 07235-10210 | ELBOW | 10001- | |
| 44 | 07002-21423 | O-RING | 10054- | |
| \0\07002-11423 | O-RING | 10001-10053 | ||
| 45 | 427-87-15313 | WIRE ASS'Y | 10598- | |
| 427-87-15312 | WIRE ASS'Y | 10001-10597 | ||
| 46 | 08052-01711 | CLIP | 10001- | |
| 47 | 01220-40608 | SCREW | 10001- | |
| 48 | 01641-20608 | WASHER | 10001- | |
| 49 | 423-35-12240 | CLIP | 10001- | |
| 50 | 421-06-11982 | SWITCH,LIMIT DIVIDER VALVE | 10580- | |
| \0\421-06-11981 | SWITCH,LIMIT DIVIDER VALVE | 10001-10579 | ||
| (\2\421-06-11980) | SWITCH,LIMIT DIVIDER VALVE | (10001-10049) | ||
| 51 | 07002-22034 | O-RING | 10054- | |
| \0\07002-12034 | O-RING | 10001-10053 |
