| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 565-43-12111 | PEDAL,ACCELERATOR | 1424- | |
| 565-43-12110 | PEDAL,ACCELERATOR | 510-1423 | ||
| 2 | 565-43-12121 | SUPPORT | 510- | |
| 3 | 01010-30616 | BOLT | 510- | |
| 4 | 01580-00605 | NUT | 510- | |
| 5 | 01602-00619 | WASHER | 510- | |
| 6 | 01016-30830 | BOLT | 1424- | |
| 01016-30835 | BOLT | 510-1423 | ||
| 7 | 01580-00806 | NUT | 510- | |
| 8 | 565-43-12131 | SHAFT | 510- | |
| 9 | 01641-00608 | WASHER | 510- | |
| 10 | 04050-01212 | PIN | 510- | |
| 11 | 04205-00825 | PIN | 1424- | |
| 04205-00832 | PIN | 510-1423 | ||
| 12 | 01641-00812 | WASHER | 1424- | |
| 01641-00812 | WASHER | 510-1423 | ||
| 13 | 04050-02012 | PIN | 1424- | |
| 04050-02012 | PIN | 510-1423 | ||
| 14 | 04211-00844 | YOKE | 1424- | |
| 281-09-11720 | END,ROD | 510-1423 | ||
| 15 | 01580-00806 | NUT | 510-1423 | |
| 16 | 04244-00808 | ROD | 1424- | |
| 04245-00807 | ROD | 510-1423 | ||
| 17 | 565-43-72210 | BRACKET | 935- | |
| 560-43-12210 | SUPPORT | 510-934 | ||
| 18 | 01010-30820 | BOLT | 935- | |
| 01010-30616 | BOLT | 510-934 | ||
| 19 | 01580-00605 | NUT | 510-934 | |
| 20 | 01602-00825 | WASHER | 935- | |
| 01602-00619 | WASHER | 510-934 | ||
| 21 | 01641-01223 | WASHER | 510-934 | |
| 22 | 04205-01232 | PIN | 510-934 | |
| 23 | 04050-03020 | PIN | 510-934 | |
| 24 | 565-43-72223 | LEVER | 1424- | |
| 565-43-72222 | LEVER | 1256-1423 | ||
| 565-43-72221 | LEVER | 1034-1255 | ||
| 565-43-72220 | LEVER | 935-1033 | ||
| 565-43-12220 | LEVER | 510-934 | ||
| 24A | 01641-21626 | WASHER | 1064-. | |
| 25 | 01598-00809 | NUT | 935-1423 | |
| 01590-00809 | NUT | 510-934 | ||
| 25A | 01010-50835 | BOLT | 935-1423 | |
| 26 | 281-43-11190 | SPACER | 935-1423 | |
| 04050-12015 | PIN | 510-934 | ||
| 27 | 565-43-12230 | ROD | 510-934 | |
| 28 | 04205-00825 | PIN | 510-934 | |
| 29 | 01641-00812 | WASHER | 510-934 | |
| 30 | 04050-02012 | PIN | 510-934 | |
| 31 | 04211-00844 | YOKE | 510-934 | |
| 32 | 01580-00806 | NUT | 510-934 | |
| 33 | 565-43-12310 | SUPPORT,L.H. | 510-934 | |
| 34 | 565-43-12410 | SUPPORT,R.H. | 510-934 | |
| 35 | 01010-30620 | BOLT | 510-934 | |
| 36 | 01580-00605 | NUT | 510-934 | |
| 37 | 01602-00619 | WASHER | 510-934 | |
| 38 | 565-43-72150 | LEVER | 510-934 | |
| 39 | 565-43-12491 | SPRING | 1424- | |
| \0\566-43-11290 | SPRING | 935-1423 | ||
| 565-43-12490 | SPRING | 510-934 | ||
| 40 | 04205-00825 | PIN | 510- | |
| 41 | 01641-00812 | WASHER | 510- | |
| 42 | 04050-02012 | PIN | 510- | |
| 43 | 565-43-72433 | ROD | 1424- | |
| 565-43-72432 | ROD | 1256-1423 | ||
| 565-43-72431 | ROD | 935-1255 | ||
| 565-43-12431 | ROD | 510-934 | ||
| 44 | 04211-00844 | YOKE | 510- | |
| 45 | 01580-00806 | NUT | 510- |
