| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 198-54-11290 | BRACKET | 1002-1012 | |
| 2 | 01010-31230 | BOLT | 1002-1012 | |
| 3 | 01602-01236 | WASHER | 1002-1012 | |
| 4 | 198-54-11272 | BRACKET | 1008-1009 | |
| 4 | 198-54-11271 | BRACKET | 1006-1007 | |
| 4 | 198-54-11270 | BRACKET | 1002-1005 | |
| 5 | 198-54-11570 | SHIM, 1.0MM | 1008-1012 | |
| 5 | 198-54-11530 | BRACKET | 1006-1008 | |
| 6 | 01010-31225 | BOLT | 1009-1012 | |
| 6 | 01010-31230 | BOLT | 1006-1008 | |
| 6 | 01010-31235 | BOLT | 1002-1005 | |
| 7 | 01602-01236 | WASHER | 1002-1012 | |
| 8 | 198-54-11281 | BRACKET | 1006-1012 | |
| 8 | 198-54-11280 | BRACKET | 1002-1005 | |
| 9 | 01010-31230 | BOLT | 1002-1012 | |
| 10 | 01602-01236 | WASHER | 1002-1012 | |
| 11 | 01010-31465 | BOLT | 1002-1012 | |
| 12 | 01602-01442 | WASHER | 1002-1012 | |
| 13 | 198-54-11330 | SPACER | 1002-1012 | |
| 14 | 198-54-11251 | COVER,R.H. | 1004-1012 | |
| 14 | 198-54-11250 | COVER,R.H. | 1002-1003 | |
| 15 | 01010-31240 | BOLT | 1002-1012 | |
| 16 | 01602-01236 | WASHER | 1002-1012 | |
| 17 | 01643-31232 | WASHER | 1002-1012 | |
| 18 | 198-54-11241 | COVER,L.H. | 1004-1012 | |
| 18 | 198-54-11240 | COVER,L.H. | 1002-1003 | |
| 19 | 01010-31240 | BOLT | 1002-1012 | |
| 20 | 01602-01236 | WASHER | 1002-1012 | |
| 21 | 01643-31232 | WASHER | 1002-1012 | |
| 22 | 198-54-14280 | COVER | 1002-1012 | |
| 23 | 01010-31230 | BOLT | 1002-1012 | |
| 24 | 01602-01236 | WASHER | 1002-1012 | |
| 25 | 01640-21223 | WASHER | 1002-1012 | |
| 26 | 01010-31235 | BOLT | 1002-1012 | |
| 27 | 01602-01236 | WASHER | 1002-1012 | |
| 28 | 01640-21223 | WASHER | 1002-1012 | |
| 29 | 198-54-14350 | COVER | 1002-1012 | |
| 30 | 01010-31240 | BOLT | 1002-1012 | |
| 31 | 01602-01236 | WASHER | 1002-1012 | |
| 32 | 01640-21223 | WASHER | 1002-1012 | |
| 33 | 198-54-14272 | BRACKET | 1009-1012 | |
| 33 | 198-54-14271 | BRACKET | 1004-1008 | |
| 33 | 198-54-14270 | BRACKET | 1002-1003 | |
| 34 | 01010-31240 | BOLT | 1009-1012 | |
| 34 | 01010-31235 | BOLT | 1002-1008 | |
| 35 | 01602-01236 | WASHER | 1009-1012 | |
| 35 | 01602-01236 | WASHER | 1002-1008 | |
| 36 | 01643-31232 | WASHER | 1009-1012 | |
| 36 | 01641-21223 | WASHER | 1002-1008 | |
| 37 | 198-54-11580 | COVER | 1009-@ | |
| 38 | 01010-31225 | BOLT | 1009-@ | |
| 39 | 01602-01236 | WASHER | 1009-@ | |
| 40 | 01643-31232 | WASHER | 1009-@ | |
| 41 | 198-54-11260 | PLATE | 1002-1003 | |
| 42 | 01010-31230 | BOLT | 1002-1003 | |
| 43 | 01602-01236 | WASHER | 1002-1003 | |
| 44 | 01010-33070 | BOLT | 1004-1012 | |
| 45 | 01601-03075 | WASHER | 1004-1012 | |
| 46 | 01643-33080 | WASHER | 1004-1012 |
