| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 144-811-1310 | GUARD,(FOR TILT DOZER) | 29849- | |
| 144-811-6111 | GUARD,(FOR STRAIGHT DOZER) | 29174- | ||
| 144-811-6110 | GUARD | 28073-29173 | ||
| 144-811-1116 | GUARD | 20054-28072 | ||
| 144-811-1114 | GUARD | 20032-20053 | ||
| 144-811-1113 | GUARD | 20024-20031 | ||
| 144-811-1112 | GUARD | 20006-20021 | ||
| 144-870-1512 | GUARD | 20000-20000 | ||
| 144-870-1511 | GUARD | 20000-20000 | ||
| 2 | 01019-22015 | BOLT | 22388- | |
| 01049-22015 | BOLT | 20024-22387 | ||
| 144-54-11260 | BOLT | 20006-20021 | ||
| 3 | 01602-02060 | WASHER | 20006- | |
| 4 | 07020-00000 | FITTING | 20006- | |
| 5 | 141-54-31211 | PLATE¤ MARK | 28073- | |
| 144-54-11340 | PLATE¤ MARK | 20054-28072 | ||
| 144-54-11341 | PLATE¤ MARK | 20024-20053 | ||
| 144-54-11340 | PLATE¤ MARK | 20006-20021 | ||
| 6 | 01225-20830 | SCREW | 20054- | |
| 01225-20830 | SCREW | 20024-20053 | ||
| 01225-20830 | SCREW | 20006-20021 | ||
| 7 | 144-54-11520 | GRILLE | 29849- | |
| 144-54-11314 | GRILLE | 20114-29848 | ||
| 144-54-11313 | GRILLE | 20054-20113 | ||
| 144-54-11312 | GRILLE | 20024-20053 | ||
| 144-54-11311 | GRILLE | 20006-20021 | ||
| 8 | 01010-31425 | BOLT | 22388- | |
| 01040-31425 | BOLT | 20054-23387 | ||
| 01040-31430 | BOLT | 20006-20053 | ||
| 9 | 01602-01442 | WASHER | 20006- | |
| 10 | 01643-31445 | WASHER | 20006- | |
| 11 | 144-54-11291 | BUMPER | 20032- | |
| 144-54-11290 | BUMPER | 20024-20031 | ||
| 12 | 01252-21230 | BOLT | 20032- | |
| 01252-31240 | BOLT | 20024-20031 | ||
| 13 | 01602-01236 | WASHER | 20024- | |
| 14 | 144-54-11422 | PLATE | 20488- | |
| \3\144-54-11421 | PLATE | 20054-20487 | ||
| (144-54-11422{144-03-11122¤} | ||||
| 01010-30814(3)) | ||||
| 144-54-11420 | COVER | 20006-20053 | ||
| 15 | 01010-30814 | BOLT | 20488- | |
| 01000-30820 | BOLT | 20006-20487 | ||
| 16 | 01602-00825 | WASHER | 20006- | |
| 17 | 144-54-11200 | CATCHER ASS'Y,R.H. | 20006- | |
| 144-54-11300 | CATCHER ASS'Y,L.H. | 20006- | ||
| 18 | 01010-31220 | BOLT | 20032- | |
| 01040-31020 | BOLT | 20006-20031 | ||
| 19 | 01602-01236 | WASHER | 20032- | |
| 01602-01030 | WASHER | 20006-20031 | ||
| 20 | 144-811-6210 | PLATE | 28073- | |
| 144-811-1221 | PLATE | 20024-28072 | ||
| 141-811-1220 | PLATE | 20006-20021 | ||
| 21 | 140-60-15460 | TUBE | 20006- | |
| 22 | 01012-31245 | BOLT | 20006- | |
| 23 | 01590-01215 | NUT | 20006- | |
| 24 | 04050-03025 | PIN | 20006- | |
| 25 | 04050-00060 | PIN | 20006- | |
| 26 | 144-54-11413 | COVER | 20054- | |
| 144-54-11412 | COVER | 20024-20053 | ||
| 144-54-11411 | COVER | 20006-20021 | ||
| 27 | 01010-31220 | BOLT | 20054- | |
| 01040-31016 | BOLT | 20006-20053 | ||
| 28 | 01602-01236 | WASHER | 20054- | |
| 01602-01030 | WASHER | 20006-20053 | ||
| 29 | 144-811-6150 | COVER | 28073- | |
| 144-54-11122 | COVER | 20024-20053 | ||
| 144-54-11121 | COVER | 20054-28072 | ||
| 30 | 01010-31225 | BOLT | 20006- | |
| 31 | 01602-01236 | WASHER | 20006- | |
| 32 | 01643-31232 | WASHER | 20006- | |
| 33 | 141-54-11170 | COVER | 20006- | |
| 34 | 131-54-11270 | PIN | 20006- | |
| 35 | 04050-01610 | PIN | 20006- | |
| 36 | 131-54-11150 | SPRING | 20006- | |
| 37 | 04205-00618 | PIN | 20006- | |
| 38 | 04050-01610 | PIN | 20006- | |
| 39 | 144-54-11134 | HOOD | 32001- | |
| 144-54-11133 | HOOD | 29174-32000 | ||
| 144-54-11131 | HOOD | 20054-29173 | ||
| 144-54-11132 | HOOD | 20024-20053 | ||
| 40 | 144-54-11250 | BRACKET | 32001- | |
| 41 | 145-54-41280 | PLATE | 32001- | |
| 42 | 01010-31235 | BOLT | 32001- | |
| 43 | 01602-01236 | WASHER | 32001- | |
| 44 | 01643-31232 | WASHER | 32001- | |
| 45 | 01010-31225 | BOLT | 20006- | |
| 46 | 01602-01236 | WASHER | 20006- | |
| 47 | 01643-31232 | WASHER | 20006- |
