| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 144-54-55813 | GUARD,RADIATOR | 46438- | |
| 2 | 01019-32015 | BOLT | 45200- | |
| 3 | 01643-32060 | WASHER | 45200- | |
| 4 | 08037-01610 | GROMMET | 45200- | |
| 5 | 144-54-24212 | FRAME | 47951- | |
| 5 | 144-54-24211 | FRAME | 45200-47950 | |
| 6 | 120-43-39361 | DAMPER | 45200- | |
| 7 | 01580-11008 | NUT | 45200- | |
| 8 | 144-54-51221 | BAR | 47951- | |
| 8 | 144-54-51220 | FRAME | 45200-47950 | |
| 9 | 01010-51840 | BOLT | 47951- | |
| 9 | 01010-51440 | BOLT | 45200-47950 | |
| 10 | 01643-31845 | WASHER | 47951- | |
| 10 | 01602-21442 | WASHER,SPRING | 45200-47950 | |
| 11 | 144-54-51960 | MASK,FRONT | 46438- | |
| 12 | 144-54-11933 | MASK,REAR | 45200- | |
| 13 | 01010-51225 | BOLT | 45200- | |
| 14 | 01602-21236 | WASHER,SPRING | 45200- | |
| 15 | 01643-31232 | WASHER | 45200- | |
| 16 | 01010-51635 | BOLT | 45200- | |
| 17 | 01643-31645 | WASHER | 45200- | |
| 18 | 144-54-51121 | COVER | 45200- | |
| 19 | 01010-51225 | BOLT | 45200- | |
| 20 | 01602-21236 | WASHER,SPRING | 45200- | |
| 21 | 01643-31232 | WASHER | 45200- | |
| 22 | 144-54-51140 | COVER | 45200- | |
| 23 | 131-54-11270 | PIN | 45200- | |
| 24 | 04050-11610 | PIN,COTTER | 45200- | |
| 25 | 09459-11033 | LOCK | 45200- | |
| 26 | 09459-01614 | SPRING | 45200- | |
| 27 | 01642-21016 | WASHER | 45200- | |
| 28 | 04050-13015 | PIN,COTTER | 45200- | |
| 29 | 144-54-51111 | HOOD | 47951- | |
| 29 | 144-54-51110 | HOOD | 45438-47950 | |
| 30 | 144-54-51131 | COVER | 47951- | |
| 30 | 144-54-51130 | COVER | 45438-47950 | |
| 31 | 01010-51235 | BOLT | 47951- | |
| 31 | 01010-51235 | BOLT | 45200-47950 | |
| 32 | 01602-21236 | WASHER,SPRING | 47951- | |
| 32 | 01602-21236 | WASHER,SPRING | 45200-47950 | |
| 33 | 01643-31232 | WASHER | 47951- | |
| 33 | 01643-31232 | WASHER | 45200-47950 | |
| 34 | 144-851-1750 | COVER | 46438-47950 | |
| 35 | 01010-51020 | BOLT | 45200-47950 | |
| 36 | 01602-21030 | WASHER,SPRING | 45200-47950 | |
| 37 | 135-54-31290 | HANDLE | 45200- | |
| 38 | 135-54-31310 | STOPPER | 45200- | |
| 39 | 01643-31032 | WASHER | 45200- | |
| 40 | 04025-00316 | PIN,SPRING | 45200- | |
| 41 | 144-54-51150 | COVER | 46438-47950 | |
| 42 | 01010-51235 | BOLT | 45200- | |
| 43 | 01602-21236 | WASHER,SPRING | 45200- | |
| 44 | 01643-31232 | WASHER | 45200- | |
| 45 | 144-54-51180 | CATCHER,R.H. | 45200- | |
| 46 | 144-54-51160 | CATCHER,L.H. | 45200- | |
| 47 | 01010-51225 | BOLT | 45200- | |
| 48 | 01602-21236 | WASHER,SPRING | 45200- | |
| 49 | 144-54-51210 | BRACKET | 45200- | |
| 50 | 01010-50820 | BOLT | 45200- | |
| 51 | 01602-20825 | WASHER,SPRING | 45200- | |
| 52 | 01010-51230 | BOLT | 46438-47950 | |
| 53 | 01602-21236 | WASHER,SPRING | 46438-47950 | |
| 54 | 01643-31232 | WASHER | 46438-47950 | |
| 55 | 07049-01215 | PLUG | 46438-47950 |
