| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 14X-54-22150 | HOOD | 4001- | |
| 2 | 14X-54-12810 | PIPE | 3034- | |
| 3 | 01010-81220 | BOLT | 3034- | |
| 4 | 130-43-64260 | COLLAR | 3034- | |
| 5 | 14X-911-1330 | HINGE | 3034- | |
| 6 | 01010-81025 | BOLT | 3034- | |
| 7 | 01643-31032 | WASHER | 3034- |
- Главная
- Каталог запчастей
- Бульдозеры
- D85ess 2 e s/n 3034 up (s6d125e 3) (for southeast asia)
- Guard
- Engine hood (without cab)(#4001 )
Поиск по каталогу
ENGINE HOOD (WITHOUT CAB)(#4001-)
