| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 09483-00312 | HOSE | 10001- | |
| 2 | 07281-00197 | CLAMP | 10001- | |
| 3 | 08036-01814 | CLIP | 10001- | |
| 4 | 01010-81020 | BOLT | 10001- | |
| 5 | 01643-31032 | WASHER | 10001- | |
| 6 | 08036-02514 | CLIP | 10001- | |
| 7 | 01010-81020 | BOLT | 10001- | |
| 8 | 01643-31032 | WASHER | 10001- | |
| 9 | 08670-02001 | INDICATOR | 10001- | |
| 10 | 08671-50170 | HOSE | 10001- | |
| 11 | 08671-50180 | HOSE | 10001- | |
| 12 | 08036-01414 | CLIP | 10001- | |
| 13 | 01010-81016 | BOLT | 10001- | |
| 14 | 01643-31032 | WASHER | 10001- | |
| 15 | 08036-03014 | CLIP | 10001- | |
| 16 | 01010-81016 | BOLT | 10001- | |
| 17 | 01643-31032 | WASHER | 10001- | |
| 18 | 01435-01030 | BOLT | 10001- | |
| 19 | 09483-00514 | HOSE | 10001- | |
| 20 | 07281-00259 | CLAMP | 10001- | |
| 428-01-11100 | HOSE ASS'Y | 10001- | ||
| 21 | 426-01-11211 | TUBE | 10001- | |
| 22 | 428-01-11150 | HOSE | 10001- | |
| 23 | 426-01-11231 | TUBE | 10001- | |
| 24 | 424-01-11110 | PLUG | 10001- | |
| 25 | 07281-00359 | CLAMP | 10001- | |
| 26 | 07000-13025 | O-RING | 10001- | |
| 27 | 01435-01025 | BOLT | 10001- | |
| 28 | 01435-01030 | BOLT | 10001- |
