| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 415-01-11110 | HOSE | 10001-11999 | |
| 2 | 07281-00709 | CLAMP | 10001-@ | |
| 3 | 415-01-11130 | CLIP | 10001-@ | |
| 4 | 415-01-11120 | BRACKET | 10001-@ | |
| 5 | 01010-51030 | BOLT | 10001-11999 | |
| 6 | 01643-31032 | WASHER | 10001-11999 | |
| 7 | 01010-51025 | BOLT | 10001-11999 | |
| 8 | 01643-31032 | WASHER | 10001-11999 | |
| 9 | 01580-11008 | NUT | 10001-11999 | |
| 10 | 415-02-11230 | TUBE | 10001-11999 | |
| 10 | 415-02-11240 | TUBE | 10001-11999 | |
| 11 | 415-02-11280 | INSULATOR | 10001-@ | |
| 12 | 07281-00709 | CLAMP | 10001-@ | |
| 13 | 01010-31020 | BOLT | 10001-11999 | |
| 14 | 01643-31032 | WASHER | 10001-11999 | |
| 415-02-11190 | CLAMP ASS'Y | 10001-11999 | ||
| 15 | 415-02-11170 | CLAMP | 10001-11999 | |
| 16 | 415-02-11210 | BOLT | 10001-11999 | |
| 17 | 415-02-11220 | NUT | 10001-11999 | |
| 18 | 415-02-11151 | BRACKET | 10001-11999 | |
| 19 | 415-02-11160 | U-BOLT | 10001-11999 | |
| 20 | 01596-01009 | NUT | 10001-@ | |
| 21 | 01010-31035 | BOLT | 10001-11999 | |
| 22 | 01643-31032 | WASHER | 10001-11999 | |
| 23 | 01580-01008 | NUT | 10001-11999 | |
| 24 | 415-02-11122 | TUBE | 10001-11999 | |
| 25 | 415-02-11140 | CLAMP | 10001-11999 | |
| 26 | 01010-51035 | BOLT | 10001-11999 | |
| 27 | 01596-01009 | NUT | 10001-11999 | |
| 28 | 01643-31032 | WASHER | 10001-11999 | |
| 29 | 01010-51240 | BOLT | 10001-11999 | |
| 30 | 01643-31232 | WASHER | 10001-11999 | |
| 31 | 01580-11210 | NUT | 10001-11999 |
