| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 567-89-75212 | COVER,L.H. | 1601- | |
| 1 | 09455-12013 | HINGE | 1601- | |
| 2 | 01010-81020 | BOLT | 1201- | |
| 3 | 01643-31032 | WASHER | 1201- | |
| 4 | 567-89-75222 | COVER,L.H. | 1601- | |
| 5 | 01010-81020 | BOLT | 1201- | |
| 6 | 01643-31032 | WASHER | 1201- | |
| 7 | 567-89-75232 | COVER,L.H. | 1601- | |
| 7 | 09455-12013 | HINGE | 1601- | |
| 8 | 01010-81020 | BOLT | 1001- | |
| 9 | 01643-31032 | WASHER | 1001- | |
| 10 | 567-89-75280 | COVER,L.H. | 1601- | |
| 11 | 01010-81020 | BOLT | 1001- | |
| 12 | 01643-31032 | WASHER | 1001- | |
| 13 | 567-89-75290 | COVER | 1601- | |
| 14 | 01010-81020 | BOLT | 1601- | |
| 15 | 01643-31032 | WASHER | 1601- | |
| 16 | 567-89-75251 | COVER,R.H. | 1601- | |
| 16 | 09455-12013 | HINGE | 1601- | |
| 17 | 01010-81020 | BOLT | 1001- | |
| 18 | 01643-31032 | WASHER | 1001- | |
| 19 | 567-89-75260 | COVER,R.H. | 1001- | |
| 20 | 01010-81020 | BOLT | 1001- | |
| 21 | 01643-31032 | WASHER | 1001- | |
| 22 | 566-54-12790 | CUSHION | 1001- | |
| 23 | 23S-54-14410 | LOCK | 1001- | |
| 24 | 01023-10412 | SCREW | 1001- | |
| 25 | 01640-20408 | WASHER | 1001- | |
| 26 | 01580-10403 | NUT | 1001- |
