| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 14X-06-14620 | WIRING HARNESS | 60001- | |
| 2 | 08038-00519 | CAP | 60001- | |
| 2A | 01580-10403 | NUT | 60202- | |
| 2B | 01601-20410 | WASHER,SPRING | 60202- | |
| 2C | 01641-20405 | WASHER | 60202- | |
| 3 | 08036-01214 | CLIP | 60001- | |
| 4 | 08053-01510 | CLIP | 60001- | |
| 5 | 01010-51016 | BOLT | 60001- | |
| 6 | 01643-31032 | WASHER | 60001- | |
| 7 | 14X-06-14181 | WIRING HARNESS | 60001- | |
| 8 | 08034-00519 | BAND | 60001- | |
| 9 | 08038-02027 | CAP | 60001- | |
| 10 | 08038-00519 | CAP | 60001- | |
| 11 | 08036-01414 | CLIP | 60001- | |
| 12 | 01643-31032 | WASHER | 60001- | |
| 13 | 08036-01414 | CLIP | 60001- | |
| 14 | 08053-00910 | CLIP | 60001- | |
| 15 | 08036-01414 | CLIP | 60001- | |
| 16 | 01010-51016 | BOLT | 60001- | |
| 17 | 01643-31032 | WASHER | 60001- | |
| 18 | 08036-01414 | CLIP | 60001- | |
| 19 | 01010-51016 | BOLT | 60001- | |
| 20 | 01643-31032 | WASHER | 60001- | |
| 21 | 08053-00910 | CLIP | 60001- | |
| 22 | 01010-51016 | BOLT | 60001- | |
| 23 | 01643-31032 | WASHER | 60001- | |
| 24 | 08036-01214 | CLIP | 60001- | |
| 25 | 14X-06-14611 | WIRING HARNESS | 60271- | |
| \3\14X-06-14610 | WIRING HARNESS | 60001-60270 | ||
| (14X-06-14611{14X-06-14122)} | ||||
| 26 | 08053-01510 | CLIP | 60001- | |
| 27 | 08038-00519 | CAP | 60001- | |
| 28 | 08038-00525 | CAP | 60001- | |
| 29 | 08036-01214 | CLIP | 60001- | |
| 30 | 01010-51016 | BOLT | 60001- | |
| 31 | 01643-31032 | WASHER | 60001- | |
| 32 | 08036-01414 | CLIP | 60001- | |
| 33 | 08036-01414 | CLIP | 60001- | |
| 34 | 08053-00910 | CLIP | 60001- | |
| 35 | 01010-51016 | BOLT | 60001- | |
| 36 | 01643-31032 | WASHER | 60001- | |
| 37 | 08034-00536 | BAND | 60001- | |
| 38 | 08028-44050 | CABLE | 60001- | |
| 39 | 01010-51016 | BOLT | 60001- | |
| 40 | 01643-31032 | WASHER | 60001- | |
| 41 | (600-815-5140) | FUEL PUMP,(NOT SHOWN) | 60001- |
