| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 134-06-65170 | BRACKET | 2001- | |
| 2 | 134-977-2532 | WIRING HARNESS | 2001- | |
| 3 | 421-06-22880 | HOLDER | 2001- | |
| 4 | 421-06-22830 | FUSE, 120A | 2001- | |
| 5 | 21X-06-31530 | DIODE | 2001- | |
| 6 | 21X-06-31540 | CONNECTOR | 2001- | |
| 7 | 04434-52710 | CLIP | 2001- | |
| 8 | 01010-81020 | BOLT | 2001- | |
| 9 | 01643-31032 | WASHER | 2001- | |
| 10 | 07095-20627 | CUSHION | 2001- | |
| 11 | 04434-53411 | CLIP | 2001- | |
| 12 | 01010-81020 | BOLT | 2001- | |
| 13 | 01643-31032 | WASHER | 2001- | |
| 14 | 421-06-22910 | BRACKET | 2001- | |
| 15 | 421-06-22920 | BRACKET | 2001- | |
| 16 | 01010-80820 | BOLT | 2001- | |
| 17 | 01643-30823 | WASHER | 2001- | |
| 18 | 08053-01510 | CLIP | 2001- | |
| 19 | 01010-81020 | BOLT | 2001- | |
| 20 | 01643-31032 | WASHER | 2001- | |
| 21 | 134-06-65151 | PLATE | 2001- | |
| 22 | 01010-81025 | BOLT | 2001- | |
| 23 | 01643-31032 | WASHER | 2001- | |
| 24 | 04434-51410 | CLIP | 2001- | |
| 25 | 04434-50610 | CLIP | 2001- | |
| 26 | 01010-81020 | BOLT | 2001- | |
| 27 | 01643-31032 | WASHER | 2001- | |
| 28 | 08193-20010 | CLIP | 2001- | |
| 29 | 04435-50510 | CLIP | 2001- | |
| 30 | 01010-81020 | BOLT | 2001- | |
| 31 | 01643-31032 | WASHER | 2001- | |
| 32 | 04434-50810 | CLIP | 2001- |
