| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 565-02-11213 | PIPE | 1424- | |
| 1 | 565-02-11212 | PIPE | 956-1423 | |
| 1 | 565-02-11211 | PIPE | 510-955 | |
| 2 | 01010-51225 | BOLT | 510-1423 | |
| 3 | 01602-21236 | WASHER | 510-1423 | |
| 4 | 6685-11-5743 | BAND | .- | |
| 4 | 6685-11-5741 | BAND | 510-. | |
| 5 | 565-02-11320 | BAND | 510- | |
| 6 | 01010-51220 | BOLT | 510- | |
| 7 | 01602-01236 | WASHER | 510- | |
| 8 | 01010-61045 | BOLT | .- | |
| 8 | 01010-31060 | BOLT | 510-. | |
| 9 | 01580-01008 | NUT | 510-1279 | |
| 9A | 01602-01030 | WASHER | 1280- | |
| 10 | 565-02-11313 | PIPE | 956- | |
| 10 | 565-02-11312 | PIPE | 935-955 | |
| 10 | \3\565-02-11311 | PIPE | 510-934 | |
| (565-02-11312(1),565-02-11241(1), | ||||
| 565-02-11330(1),01010-31030(1)) | ||||
| 11 | 565-02-11241 | BAND | 935- | |
| 11 | 565-02-11241 | BAND | 510-934 | |
| 11 | (\2\565-02-11240) | BAND | (510-934) | |
| 12 | 01010-31030 | BOLT | 1424- | |
| 12 | 01010-31030 | BOLT | 935-1423 | |
| 12 | 01010-31030 | BOLT | 510-934 | |
| 12A | 01010-31035 | BOLT | 1424- | |
| 13 | 01580-01008 | NUT | 1280- | |
| 13 | 01580-01008 | NUT | 935-1279 | |
| 13 | 01580-01008 | NUT | 510-934 | |
| 13A | 01602-01030 | WASHER | 1280- | |
| 13B | 01643-31032 | WASHER | 1424- | |
| 14 | 565-02-11392 | PIPE | 1424- | |
| 14 | 565-02-11391 | PIPE | 935-1423 | |
| 14 | 565-02-11390 | PIPE | 510-934 | |
| 15 | 565-02-11380 | BAND | 510-1423 | |
| 16 | 01010-31020 | BOLT | 570-934 | |
| 16 | 01010-30820 | BOLT | 510-569 | |
| 16A | 01010-31030 | BOLT | 935-1423 | |
| 17 | 01602-01030 | WASHER | 570-934 | |
| 17 | 01602-00825 | WASHER | 510-569 | |
| 17A | 01580-01008 | NUT | 1280-1423 | |
| 17A | 01580-01008 | NUT | 935-1279 | |
| 17B | 01602-01030 | WASHER | 1280-1423 | |
| 18 | 01010-31030 | BOLT | 510-1423 | |
| 19 | 01580-01008 | NUT | 1280-1423 | |
| 19 | 01580-01008 | NUT | 510-1279 | |
| 19A | 01602-01030 | WASHER | 1280-1423 | |
| 20 | 565-02-11261 | BAND | 1279- | |
| 20 | \0\565-02-11260 | BAND | 510-1278 | |
| 21 | 01010-51030 | BOLT | 510- | |
| 22 | 01580-01008 | NUT | 1280- | |
| 22 | 01580-01008 | NUT | 510-1279 | |
| 22A | 01602-01030 | WASHER | 1280- | |
| 23 | 565-02-11351 | MUFFLER | 1256- | |
| 23 | 565-02-11350 | MUFFLER | 510-1255 | |
| 24 | 565-02-11290 | BAND | 1424- | |
| 24 | 565-02-11180 | BAND | 510-1423 | |
| 25 | 01010-31020 | BOLT | 570-1423 | |
| 25 | 01010-30820 | BOLT | 510-569 | |
| 26 | 01602-01030 | WASHER | 570-1423 | |
| 26 | 01602-00825 | WASHER | 510-569 | |
| 01010-31030 | BOLT | 510-1423 | ||
| 27 | 01010-31045 | BOLT | 1424- | |
| 28 | 01580-01008 | NUT | 1280-1423 | |
| 28 | 01580-01008 | NUT | 510-1279 | |
| 28A | 01602-01030 | WASHER | 1280- | |
| 28B | 01643-31032 | WASHER | 1424- | |
| 29 | 565-02-11361 | PIPE | 1256- | |
| 29 | 565-02-11360 | PIPE | 510-1255 | |
| 30 | 565-02-11261 | BAND | 1279- | |
| 30 | \0\565-02-11260 | BAND | 1256-1278 | |
| 30 | 565-02-11340 | BAND | 510-1255 | |
| 31 | 01010-31030 | BOLT | 510- | |
| 32 | 01580-01008 | NUT | 1280- | |
| 32 | 01580-01008 | NUT | 510-1279 | |
| 32A | 01602-01030 | WASHER | 1280- | |
| 33 | 565-02-11330 | PIPE,FLEXIBLE | 935-1423 | |
| 34 | 6631-11-5820 | JOINT | 956- | |
| 35 | 565-02-11520 | RING | 1424- | |
| 35 | \0\6112-13-5250 | RING | 956-1423 | |
| 36 | 565-02-11440 | BRACKET | 956-1423 | |
| 37 | 01010-31240 | BOLT | 956- | |
| 38 | 01580-01210 | NUT | 956- | |
| 39 | 01602-01236 | WASHER | 956- | |
| 40 | 07042-20108 | PLUG | 956- | |
| 41 | 02010-70825 | BOLT | 956- | |
| 42 | 01602-01338 | WASHER | 956- | |
| 43 | 565-02-11430 | BRACKET | 956- | |
| 44 | 565-02-11910 | PLATE | 1256-1278 | |
| 45 | 565-02-11530 | BRACKET | 1424- | |
| 46 | 565-03-12230 | CUSHION | 1424- | |
| 47 | 01010-31285 | BOLT | 1424- | |
| 48 | 566-35-42430 | PLATE | 1424- | |
| 49 | 01598-01214 | NUT | 1424- |
