| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 56B-06-53470 | Wiring Harness | 10001- | |
| 2 | 04434-51010 | Clip | 10001- | |
| 3 | 01010-81020 | Bolt | 10001- | |
| 4 | 01643-31032 | Washer | 10001- | |
| 5 | 600-816-2720 | Sensor | 10001- | |
| 6 | 01010-80620 | Bolt | 10001- | |
| 7 | 01643-30623 | Washer | 10001- | |
| 8 | 6253-81-4410 | Clip | 10001- | |
| 9 | 01010-81020 | Bolt | 10001- | |
| 10 | 01643-31032 | Washer | 10001- | |
| 11 | 01010-80620 | Bolt | 10001- | |
| 12 | 01643-30623 | Washer | 10001- | |
| 13 | 6253-81-4410 | Clip | 10001- | |
| 14 | 01010-81020 | Bolt | 10001- | |
| 15 | 01643-31032 | Washer | 10001- | |
| 16 | 600-816-2830 | Sensor | 10001- | |
| 17 | 600-816-2811 | Sensor | 10001- | |
| 18 | 56B-02-51392 | Cover | 10001- | |
| 19 | 01010-81225 | Bolt | 10001- | |
| 20 | 01643-31232 | Washer | 10001- | |
| 21 | 01584-01008 | Nut | 10001- |
