| Item | Part No. | Part Name | Qty | Serial No. |
| TRANSMISSION (SEE FIG. F3300-01A0) | ||||
| 1 | 711-20-31120 | PUMP | ||
| 2 | 711-20-31140 | RETAINER | ||
| 3 | 569-13-51190 | GUIDE | ||
| 4 | 01010-81040 | BOLT | ||
| 5 | 01643-31032 | WASHER | ||
| 6 | 711-40-21511 | TURBINE ASSEMBLY | ||
| N/I | 711-40-21520 | TURBINE | ||
| N/I | 711-40-21531 | BOSS | ||
| N/I | 711-70-11540 | PLATE | ||
| N/I | 711-70-11550 | RIVET | ||
| 7 | 711-20-32110 | STATOR | ||
| 8 | 711-20-32120 | RACE | ||
| 9 | 01010-81025 | BOLT | ||
| 10 | 01643-31032 | WASHER | ||
| 11 | 711-20-12141 | BUSHING | ||
| 12 | 711-20-12160 | WHEEL | ||
| 13 | 04260-00635 | BALL | ||
| 14 | 711-20-32130 | RACE | ||
| 15 | 56B-13-12521 | SHAFT, STATOR | ||
| 16 | 56B-13-12530 | SLEEVE | ||
| 17 | 14X-15-19220 | SEAL RING | ||
| 18 | 568-13-13351 | BEARING | ||
| 19 | 711-40-12680 | NUT | ||
| 20 | 07043-00108 | PLUG, TAPERED | ||
| 21 | 01010-61645 | BOLT | ||
| 22 | 01643-31645 | WASHER |
