| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 8248-62-1440 | HOSE | 1002- | |
| 2 | 8248-62-1260 | HOSE | 1002- | |
| 3 | 8248-62-1280 | HOSE | 1002- | |
| 4 | 8248-62-1270 | HOSE | 1002- | |
| 5 | 8248-62-1310 | ELBOW | 1002- | |
| 6 | 07002-01423 | O-RING | 1002- | |
| 7 | 205-62-55270 | NIPPLE | 1002- | |
| 8 | 07002-01423 | O-RING | 1002- | |
| 9 | 07102-20310 | HOSE | 1002- | |
| 10 | 07236-10315 | ELBOW | 1002- | |
| 11 | 07002-12034 | O-RING | 1002- | |
| 12 | 205-62-55270 | NIPPLE | 1002- | |
| 13 | 07002-01423 | O-RING | 1002- | |
| 14 | 8248-62-1250 | HOSE | 1002- | |
| 15 | 702-16-53240 | PLUG | 1002- | |
| 16 | 07000-12018 | O-RING | 1002- | |
| 17 | 04434-51412 | CLIP | 1002- | |
| 18 | 01010-81220 | BOLT | 1002- | |
| 19 | 01643-31232 | WASHER | 1002- | |
| 20 | 04435-52212 | CLIP | 1002- | |
| 21 | 01010-81220 | BOLT | 1002- | |
| 22 | 01643-31232 | WASHER | 1002- | |
| 23 | 20Y-62-18890 | BOLT | 1002- | |
| 24 | 07000-12015 | O-RING | 1002- |
