| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 20Y-62-22810 | Band, Yellow | 2616-@ | |
| 2 | 20Y-62-22820 | Band, Blue | 2616-@ | |
| 3 | 20Y-62-22830 | Band, White | 2616-@ | |
| 4 | 20Y-62-22840 | Band, Black | 2616-@ | |
| 5 | 20Y-62-22850 | Band, Green | 2616-@ | |
| 6 | 02753-00542 | Hose, Face Seal Type | 2616-@ | |
| 7 | 02753-00543 | Hose, Face Seal Type | 2616-@ | |
| 8 | 02753-00253 | Hose, Face Seal Type | 2616-@ | |
| 9 | 02753-00256 | Hose, Face Seal Type | 2616-@ | |
| 10 | 02762-00346 | Hose, Face Seal Type | 2616-@ | |
| 11 | 8240-62-1390 | Bracket | 2616-@ | |
| 12 | 02896-11015 | O-ring | 2616-@ | |
| 13 | 02896-11012 | O-ring | 2616-@ | |
| 14 | 01010-81225 | Bolt | 2616-@ | |
| 15 | 01643-31232 | Washer | 2616-@ | |
| 16 | 113-899-7950 | Clip | 2616-@ | |
| 17 | 01010-81285 | Bolt | 2616-@ | |
| 18 | 01643-31232 | Washer | 2616-@ | |
| 19 | 175-61-17240 | Collar | 2616-@ | |
| 20 | 20Y-62-15960 | Clip | 2616-@ | |
| 21 | 20Y-62-15950 | Clip | 2616-@ | |
| 22 | 01010-81225 | Bolt | 2616-@ | |
| 23 | 01643-31232 | Washer | 2616-@ | |
| 24 | 01010-81230 | Bolt | 2616-2760 | |
| 25 | 01643-31232 | Washer | 2616-2760 | |
| 26 | 8240-62-1422 | Cover | 2616-@ | |
| 27 | 09412-00003 | Seal, Door | 2616-@ | |
| 28 | 01010-81230 | Bolt | 2616-@ | |
| 29 | 01643-31232 | Washer | 2616-@ | |
| 30 | 07094-10315 | Clamp | 2616-@ | |
| 31 | 07095-00317 | Cushion | 2616-@ | |
| 32 | 07094-30518 | Clamp | 2616-@ | |
| 33 | 07095-00524 | Cushion | 2616-@ | |
| 34 | 01011-81210 | Bolt | 2616-@ | |
| 35 | 01643-31232 | Washer | 2616-@ | |
| 36 | 04435-51512 | Clip | 2616-@ | |
| 37 | 01010-81225 | Bolt | 2616-@ | |
| 38 | 01643-31232 | Washer | 2616-@ | |
| 39 | 04434-51312 | Clip | 2616-@ | |
| 40 | 01010-81225 | Bolt | 2616-@ | |
| 41 | 01643-31232 | Washer | 2616-@ | |
| 42 | 20Y-62-22810 | Band, Yellow | 2616-@ | |
| 43 | 20Y-62-22820 | Band, Blue | 2616-@ | |
| 44 | 20Y-62-22840 | Band, Black | 2616-@ | |
| 45 | 20Y-62-22850 | Band, Green | 2616-@ | |
| 46 | 02753-00519 | Hose, Face Seal Type | 2616-@ | |
| 47 | 02753-00518 | Hose, Face Seal Type | 2616-@ | |
| 48 | 02753-00217 | Hose, Face Seal Type | 2616-@ | |
| 49 | 02753-00214 | Hose, Face Seal Type | 2616-@ | |
| 50 | 02763-00305 | Hose, Face Seal Type | 2616-@ | |
| 51 | 04434-51512 | Clip | 2616-@ | |
| 52 | 01010-81225 | Bolt | 2616-@ | |
| 53 | 01643-31232 | Washer | 2616-@ | |
| 54 | 8240-62-1760 | Bracket | 2616-@ | |
| 55 | 20Y-62-15960 | Clip | 2616-@ | |
| 56 | 01010-81225 | Bolt | 2616-@ | |
| 57 | 01643-31232 | Washer | 2616-@ | |
| 58 | (8240-62-1440) | Bracket | - |
