| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 19M-54-22110 | FENDER,L.H. | 10012- | |
| 2 | 19M-54-22120 | FENDER,R.H. | 10012- | |
| 3 | 01011-63945 | BOLT | 10012- | |
| 3A | 01011-63920 | BOLT | 10012- | |
| 4 | 19M-54-12450 | WASHER | 10003- | |
| 5 | 01010-63095 | BOLT | 10003- | |
| 6 | 01643-33080 | WASHER | 10001- | |
| 7 | 01010-62460 | BOLT | 10001- | |
| 8 | 20X-46-11280 | WASHER | 10012- | |
| 9 | 19M-54-14870 | BRACKET | 10001- | |
| 10 | 19M-54-22130 | BRACKET | 10012- | |
| 11 | 01010-62455 | BOLT | 10001- | |
| 11A | 01010-62460 | BOLT | 10003- | |
| 12 | 01643-32460 | WASHER | 10001- | |
| 13 | 19M-06-14280 | BRACKET | 10001- | |
| 14 | 19M-06-14290 | BRACKET | 10001- | |
| 15 | 01010-81230 | BOLT | 10001- | |
| 16 | 01643-31232 | WASHER | 10001- | |
| 17 | 195-54-43110 | COVER | 10001- | |
| 18 | 195-54-43260 | BOLT | 10012- | |
| 19 | 205-06-62460 | WASHER | 10001- | |
| 20 | 19M-54-15390 | COVER | 10001- | |
| 21 | 195-54-43260 | BOLT | 10001- | |
| 22 | 205-06-62460 | WASHER | 10001- | |
| 23 | 19M-54-12522 | CASE,L.H. | 10001- | |
| 24 | 19M-54-12560 | HINGE (WELDED) | 10001- | |
| 25 | 19M-54-12532 | CASE,R.H. | 10001- | |
| 26 | 19M-54-12560 | HINGE (WELDED) | 10001- | |
| 27 | 209-54-12280 | HANDLE | 10001- | |
| 28 | 205-54-76530 | CATCHER | 10001- | |
| 29 | 205-54-67660 | SUPPORT | 10001- | |
| 30 | 01010-80820 | BOLT | 10001- | |
| 31 | 01643-30823 | WASHER | 10001- | |
| 32 | 19M-54-12850 | LINK | 10001- | |
| 33 | 04205-01022 | PIN | 10001- | |
| 34 | 04050-13018 | PIN,COTTER | 10001- | |
| 35 | 01642-21016 | WASHER | 10001- | |
| 36 | 04050-13018 | PIN,COTTER | 10001- | |
| 37 | 01642-21016 | WASHER | 10001- | |
| 38 | 01010-81230 | BOLT | 10001- | |
| 39 | 01643-31232 | WASHER | 10001- | |
| 40 | 19M-54-00020 | SHIM ASS'Y | 10001- | |
| 40 | \6\ | SHIM, 1.0MM | 10001- | |
| 40 | \6\ | SHIM, 0.5MM | 10001- | |
| 41 | 19M-54-16360 | PLATE, 1.0MM | 10003- | |
| 42 | 19M-54-16370 | PLATE, 4.5MM | 10003- | |
| 43 | 19M-54-16380 | PLATE, 4.5MM | 10003- | |
| 44 | 19M-54-23830 | PLATE | 10012- | |
| 45 | 19M-54-25760 | COVER | 10012- | |
| 46 | 19M-54-16180 | BRACKET | 10012- | |
| 47 | 175-54-34170 | WASHER | 10012- | |
| 48 | 01010-81225 | BOLT | 10012- | |
| 49 | 195-54-42981 | CAP | 10012- | |
| 50 | 01010-81225 | BOLT | 10012- | |
| 51 | 175-54-34170 | WASHER | 10012- | |
| 52 | 198-06-46230 | BRACKET | 10038- | |
| 53 | 01010-81225 | BOLT | 10038- | |
| 54 | 01643-31232 | WASHER | 10038- | |
| 55 | 04434-51412 | CLIP | 10038- | |
| 56 | 01010-81220 | BOLT | 10038- | |
| 57 | 01643-31232 | WASHER | 10038- | |
| 58 | 01010-81220 | BOLT | 10038- | |
| 59 | 01643-31232 | WASHER | 10038- |
