| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 64709 | SPACER, MOUNTING | ||
| 2 | 114307 | BRACE, TUBE | ||
| 3 | 216187 | SEAL, O-RING | ||
| 4 | 3089232 | BOLT | ||
| 5 | 3089321 | SPACER, MOUNTING | ||
| 6 | 3089955 | GASKET, CONNECTION | ||
| 3090400 | UNION, MALE | |||
| 7 | (NSS) | UNION, MALE | ||
| 8 | 3679139 | SEAL, O-RING | ||
| 9 | 3922794 | SEAL, O-RING | ||
| 10 | 3093828 | NUT | ||
| 11 | 3093957 | BOLT | ||
| 12 | 3171784 | BRACKET, WATER TUBE | ||
| 13 | 3175058 | CLIP | ||
| 3331873 | UNION, MALE | |||
| 14 | (NSS) | UNION, MALE | ||
| 15 | 3627695 | SEAL, O-RING | ||
| 16 | 3678786 | SEAL, O-RING | ||
| 17 | 3410940 | HOSE, FLEXIBLE | ||
| 18 | 3410941 | HOSE, FLEXIBLE | ||
| 19 | 3410942 | HOSE, FLEXIBLE | ||
| 20 | 3410943 | HOSE, FLEXIBLE | ||
| 21 | 3411019 | HOSE, FLEXIBLE | ||
| 22 | 3411020 | HOSE, FLEXIBLE | ||
| 23 | 3411021 | HOSE, FLEXIBLE | ||
| 24 | 3411022 | HOSE, FLEXIBLE | ||
| 25 | 3411023 | HOSE, FLEXIBLE | ||
| 26 | 4080142 | HOSE, FLEXIBLE | ||
| 3411129 | ELBOW, MALE UNION | |||
| 27 | (NSS) | ELBOW, MALE UNION | ||
| 28 | 3679139 | SEAL, O-RING | ||
| 29 | 3922794 | SEAL, O-RING | ||
| 30 | 3629451 | CLIP | ||
| 31 | 3629452 | CLIP | ||
| 32 | 3902460 | BOLT (M10-1.50x25) | ||
| 33 | 3903112 | BOLT (M10-1.50x30) | ||
| 34 | 3903990 | BOLT (M10-1.50x20) |
