| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 68152-B | CLIP | ||
| 2 | 193734 | SEAL, O-RING | ||
| 3 | 3082396 | CONNECTION, FUEL BLOCK | ||
| 4 | 3089501 | SEAL, RECTANGULAR RING | ||
| 5 | 3171693 | BOLT | ||
| 6 | 3171694 | CONNECTION, FUEL BLOCK | ||
| 7 | 3171695 | GASKET, CONNECTION | ||
| 8 | 3171696 | TUBE, FUEL TRANSFER | ||
| 9 | 3171963 | WASHER, SEALING | ||
| 10 | 3332104 | CONNECTION, FUEL BLOCK | ||
| 11 | 3332181 | GASKET, FUEL MANIFOLD | ||
| 3678611 | PLUG, THREADED | |||
| 12 | (NSS) | PLUG, THREADED (M27-2) | ||
| 13 | 3678606 | SEAL, O-RING | ||
| 14 | 3900626 | BOLT (M6-1.00x12) | ||
| 15 | 3093957 | BOLT | ||
| 16 | 3901445 | BOLT (M8-1.25x45) | ||
| 17 | 3901937 | BOLT (M6-1.00x45) | ||
| 18 | 3902460 | BOLT (M10-1.50x25) | ||
| 19 | 3927220 | BOLT | ||
| 20 | 4000843 | BRACE, TUBE | ||
| 21 | 4000844 | BRACE, TUBE | ||
| 22 | 4000847 | NUT, LOCK | ||
| 23 | 4065385 | HOSE, FLEXIBLE | ||
| 4001633 | CONNECTOR, MALE | |||
| 24 | 3678912 | SEAL, O-RING | ||
| 25 | 3922794 | SEAL, O-RING | ||
| 26 | (NSS) | CONNECTOR, MALE | ||
| 27 | 4000887 | HOSE, FLEXIBLE | ||
| 28 | 3678923 | PLUG, THREADED | ||
| 29 | (NSS) | PLUG, THREADED | ||
| 30 | 3678925 | SEAL, O-RING | ||
| 31 | 4001104 | MANIFOLD, FUEL |
