| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 428-04-A1210 | FUEL TANK | A50001 -- | |
| 2 | 01011-63025 | BOLT | A50001 -- | |
| 3 | 01010-63080 | BOLT | A50001 -- | |
| 4 | 01643-33080 | WASHER | A50001 -- | |
| 5 | 416-855-1190 | SHIM, 0.5MM | A50001 -- | |
| 6 | 421-04-11260 | CAP | A50013-- | |
| 7 | 07056-18416 | STRAINER | A50013-- | |
| 8 | 427-04-21221 | COVER | A50001 -- | |
| 9 | 07043-70211 | PLUG | A50001 -- | |
| 10 | 07000-15200 | O-RING | A50001 -- | |
| 11 | 01435-01025 | BOLT | A50001 -- | |
| 12 | 416-04-10131 | VALVE | A50001 -- | |
| 13 | 419-04-11120 | COVER | A50001 -- | |
| 14 | 01435-00816 | BOLT | A50001 -- | |
| 15 | 428-04-11151 | ROD | A50001 -- | |
| 16 | 428-04-11160 | PLATE | A50001 -- | |
| 17 | 01010-81225 | BOLT | A50001 -- | |
| 18 | 01643-31232 | WASHER | A50001 -- | |
| 19 | 01643-51032 | WASHER | A50001 -- | |
| 20 | 04050-12018 | PIN | A50001 -- | |
| 21 | 426-04-11210 | HANDLE | A50001 -- | |
| 22 | 01643-30623 | WASHER | A50001 -- | |
| 23 | 01580-10605 | NUT | A50001 -- | |
| 24 | 421-60-11622 | GAUGE, SIGHT | A50001 -- | |
| 25 | 07002-15234 | O-RING | A50001 -- | |
| 26 | 7861-92-4850 | SENSOR, FUEL | A50001 -- | |
| 27 | 07000-12085 | O-RING | A50001 -- | |
| 28 | 04434-50610 | CLIP | A50001 -- | |
| 29 | 01435-01016 | BOLT | A50001 -- | |
| 30 | 566-98-15200 | NIPPLE ASSEMBLY | A50001 -- | |
| 31 | 566-98-15300 | CAP ASSEMBLY | A50001 -- | |
| 32 | 566-98-15100 | VENT ASSEMBLY | A50001 -- | |
| 33 | 01435-00814 | BOLT | A50001 -- | |
| 34 | 427-U49-2110 | COVER | A50001 -- | |
| 35 | 07042-70415 | PLUG | A50001 -- |
