| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 424-06-A1150 | WIRING HARNESS, REAR FRAME | A30001-UP- | |
| 421-06-11970 | DIODE | A30001-UP- | ||
| 2 | 421-06-22851 | WIRING HARNESS, BULKHEAD | A30001-UP- | |
| 421-06-11970 | DIODE | A30001-UP- | ||
| 3 | 08028-12045 | WIRE | A30001-UP- | |
| 4 | 01010-81016 | BOLT | A30001-UP- | |
| 5 | 01643-31032 | WASHER | A30001-UP- | |
| 6 | 421-06-22660 | BRACKET | A30001-UP- | |
| 7 | 01435-01016 | BOLT | A30001-UP- | |
| 8 | 04434-52212 | CLIP | A30001-UP- | |
| 9 | 42A-16-11210 | PLATE | A30001-UP- | |
| 10 | 01435-01020 | BOLT | A30001-UP- | |
| 11 | 04434-53412 | CLIP | A30001-UP- | |
| 12 | 04434-52712 | CLIP | A30001-UP- | |
| 13 | 08036-02514 | CLIP | A30001-UP- | |
| 14 | 08036-01414 | CLIP | A30001-UP- | |
| 15 | 08053-00910 | CLIP | A30001-UP- | |
| 16 | 08036-01014 | CLIP | A30001-UP- | |
| 17 | 08053-01512 | CLIP | A30001-UP- | |
| 18 | 01435-01016 | BOLT | A30001-UP- | |
| 19 | 04434-51410 | CLIP - WITH 3/8 IN. CONDUIT | A30001-A30163- | |
| OR | ||||
| 19 | 04434-51910 | CLIP - WITH 1/2 IN. CONDUIT | A30164-UP- | |
| 20 | 04434-51010 | CLIP | A30001-UP- | |
| 21 | 01435-01016 | BOLT | A30001-UP- | |
| F1 - EFFECTIVE S/N A30164-UP, CONDUIT WAS CHANGED FROM3/8 INCH TO 1/2 INCH. | ||||
