| Item | Part No. | Part Name | Qty | Serial No. |
| 714-13-X0040 | TRANSMISSION ASSEMBLY | A70001-UP- | ||
| 1 | 711-57-00300 | TORQUE CONVERTER ASSEMBLY (SEE FIG. F4350-70A0) | ||
| 714-13-11110 | CASE ASSEMBLY, FRONT | A70001-UP- | ||
| 2 | (NSS) | CASE, FRONT | A70001-UP- | |
| 3 | 714-12-16510 | SHAFT, IDLER | A70001-UP- | |
| 714-13-11121 | CASE ASSEMBLY, REAR | A70001-UP- | ||
| 4 | (NSS) | CASE, REAR | A70001-UP- | |
| 5 | 07043-70312 | PLUG | A70001-UP- | |
| 6 | 714-11-19390 | BALL | A70001-UP- | |
| 7 | 419-15-12750 | ORIFICE | A70001-UP- | |
| 8 | 07042-80108 | PLUG | A70001-UP- | |
| 9 | 07043-70617 | PLUG | A70001-UP- | |
| 10 | 07043-70617 | PLUG | A70001-UP- | |
| 11 | 07043-70211 | PLUG | A70001-UP- | |
| 12 | 21T-38-11390 | BUSHING | A70001-UP- | |
| 13 | 07043-70108 | PLUG | A70001-UP- | |
| 14 | 04020-01434 | PIN, DOWEL | A70001-UP- | |
| 15 | 01010-E1240 | BOLT | A70001-UP- | |
| 16 | 01010-E1235 | BOLT | A70001-UP- | |
| 17 | 01010-E1295 | BOLT | A70001-UP- | |
| 18 | 01010-E1265 | BOLT | A70001-UP- | |
| 19 | 01011-E1225 | BOLT | A70001-UP- | |
| 20 | 01643-31232 | WASHER | A70001-UP- | |
| N/I | 419-15-18131 | LIQUID GASKET | A70001-UP- | |
| 21 | O-RING (SEE FIG. F4300-02A0) | A70001-UP- | ||
