| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 312713621 | PEDAL | A90002-- | |
| 2 | 801200667 | SCREW (CAB ONLY) | A90002-- | |
| 2 | 801200673 | SCREW (CANOPY ONLY) | A90002-- | |
| 3 | 312713063 | SUPPORT, PEDAL | A90002-- | |
| 4 | 801015109 | BOLT | A90002-- | |
| 5 | 802170002 | WASHER | A90002-- | |
| 6 | 805630028 | BUSHING | A90002-- | |
| 7 | 312713062 | SUPPORT | A90002-- | |
| 8 | 802250020 | RING, SNAP | A90002-- | |
| 9 | 802720020 | FORK | A90002-- | |
| 10 | 802725020 | PIN, PEDAL | A90002-- | |
| 11 | 801920105 | NUT | A90002-- | |
| 12 | 801852410 | NUT, LOCK | A90002-- | |
| 13 | 805850015 | JOINT | A90002-- | |
| 14 | 312713626 | SPACER (CANOPY ONLY) | A90002-- | |
| 15 | 801015556 | BOLT | A90002-- |
