| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 360708067 | WHEEL, CAP AND STEERING | A20001-- | |
| 2 | 312608050 | NUT, SELF-LOCKING (W/WASHER) | A20001-- | |
| 3 | 801104125 | SCREW | A20001-- | |
| 4 | 802170002 | WASHER | A20001-- | |
| 5 | 816212396 | BOOT | A20001-- |
- Главная
- Каталог запчастей
- Экскаваторы погрузчики
- Wb140 2n s/n a20001 a20636
- Operator's compartment and control system
- Fig. k6580 01a0 adjustable guide canopy
Поиск по каталогу
FIG. K6580-01A0 ADJUSTABLE GUIDE - CANOPY
