| Item | Part No. | Part Name | Qty | Serial No. |
| 427-70-00070 | BELLCRANK ASS'Y | |||
| 1 | 427-70-11170 | BELLCRANK | ||
| 2 | 428-70-11860 | BUSHING | ||
| 3 | 427-09-11110 | SEAL, DUST | ||
| 4 | 07020-00000 | FITTING, GREASE | ||
| 5 | 427-70-11963 | PIN | ||
| 6 | 01010-82450 | BOLT | ||
| 7 | 427-70-11480 | WASHER | ||
| 8 | 07049-01620 | PLUG | ||
| 427-70-00061 | LINK ASS'Y | |||
| 9 | 427-70-11161 | LINK | ||
| 10 | 427-N42-1130 | BUSHING | ||
| 11 | 427-N42-1130 | BUSHING | ||
| 12 | 07020-00000 | FITTING, GREASE | ||
| 13 | 427-09-11120 | SEAL, DUST | ||
| 14 | 427-N42-1210 | O-RING | ||
| 15 | 426-09-11150 | BOLT | ||
| 16 | 01641-20608 | WASHER | ||
| 17 | 01596-00606 | NUT | ||
| 18 | 427-N42-1120 | PIN | ||
| 19 | 01010-82035 | BOLT | ||
| 20 | 427-70-11290 | WASHER | ||
| 21 | 07049-01620 | PLUG | ||
| 22 | 427-70-11440 | SHIM | ||
| 427-70-11450 | SHIM | |||
| 23 | 427-N42-1150 | PIN | ||
| 24 | 07020-00000 | FITTING, GREASE | ||
| 25 | 07049-01620 | PLUG | ||
| 26 | 427-09-11120 | SEAL, DUST | ||
| 27 | 427-70-11941 | PIN | ||
| 28 | 427-70-11420 | SHIM, 1.5MM | ||
| 427-70-11430 | SHIM, 3.0MM | |||
| 29 | 10101-82035 | BOLT | ||
| 30 | 427-70-11290 | WASHER | ||
| 31 | 07049-01620 | PLUG |
