| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 20Y-06-24820 | HARNESS, WIRING | ||
| 2 | 20Y-06-A2290 | HARNESS, RESISTOR | ||
| 3 | 08038-10519 | CAP | ||
| 4 | 08038-10525 | CAP | ||
| 5 | 362-03-11550 | BRACKET | ||
| 6 | 08036-01214 | CLIP | ||
| 7 | 01010-81025 | BOLT | ||
| 8 | 01643-31032 | WASHER | ||
| 9 | 08036-01214 | CLIP | ||
| 10 | 08036-01214 | CLIP | ||
| 11 | 01010-81225 | BOLT | ||
| 12 | 01643-31232 | WASHER | ||
| 13 | SENSOR, OIL LEVEL (SEE PG A-102) | |||
| 14 | 01010-80612 | BOLT | ||
| 15 | 01641-20608 | WASHER | ||
| 16 | 7861-92-2310 | SENSOR, PICK-UP |
