| Item | Part No. | Part Name | Qty | Serial No. |
| 205-27-00088 | FINAL DRIVE ASS'Y | 1002- | ||
| 1 | 205-27-71481 | SHAFT | 1002- | |
| 150-27-00028 | FLOATING SEAL ASS'Y | 1002- | ||
| 2 | 150-27-00262 | SEAL RING ASS'Y | 1002- | |
| \6\ | RING,SEAL | 1002- | ||
| 3 | 144-873-0310 | O-RING ASS'Y | 1002- | |
| \6\ | O-RING | 1002- | ||
| 4 | 20Y-27-11570 | BEARING | 1002- | |
| 5 | 205-27-71471 | HUB | 1002- | |
| 6 | 07044-12412 | PLUG | 1002- | |
| 7 | 07002-02434 | O-RING | 1002- | |
| 8 | 205-27-71281 | SPROCKET | 1002- | |
| 9 | 205-27-71670 | BOLT | 1002- | |
| 10 | 20Y-27-11310 | SPACER¤ 4.85MM | 1002- | |
| 11 | 205-27-71531 | GEAR | 1002- | |
| 12 | 205-27-71610 | PLATE | 1002- | |
| 13 | 01010-50820 | BOLT | 1002- | |
| 14 | 01643-50823 | WASHER | 1002- | |
| 15 | 205-27-71630 | GEAR | 1002- | |
| 16 | 04020-01842 | PIN,DOWEL | 1002- | |
| 17 | 205-27-71680 | BOLT | 1002- | |
| 18 | 205-27-71550 | GEAR | 1002- | |
| 19 | 205-27-71510 | CARRIER | 1002- | |
| 20 | 205-27-00070 | PLANETARY GEAR A. | 1002- | |
| 21 | 205-27-71560 | BEARING | 1002- | |
| 22 | 205-27-71582 | PIN | 1002- | |
| 23 | 205-27-71592 | COLLAR | 1002- | |
| 24 | 04020-00616 | PIN,DOWEL | 1002- | |
| 25 | 01010-51465 | BOLT | 1002- | |
| 26 | 20Y-27-11250 | SPACER | 1002- | |
| 27 | 205-27-71520 | GEAR | 1002- | |
| 28 | 205-27-71360 | BUTTON | 1002- | |
| 29 | 205-27-71492 | COVER | 1002- | |
| 30 | 07040-12414 | PLUG | 1002- | |
| 31 | 07002-02434 | O-RING | 1002- | |
| 32 | 01010-51685 | BOLT | 1002- | |
| 33 | 01643-31645 | WASHER | 1002- | |
| 34 | 205-27-71131 | COUPLING | 1002- | |
| 35 | 07000-05190 | O-RING | 1002- | |
| 36 | 01010-51670 | BOLT | 1002- | |
| 37 | 01643-31645 | WASHER | 1002- | |
| 38 | 01010-51670 | BOLT | 1002- | |
| 39 | 01643-31645 | WASHER | 1002- | |
| ADJUSTMENT SPACER | ||||
| 10 | 20Y-27-11320 | SPACER¤ 4.90MM | 1002- | |
| 20Y-27-11330 | SPACER¤ 4.95MM | 1002- | ||
| 20Y-27-11340 | SPACER¤ 5.00MM | 1002- | ||
| 20Y-27-11350 | SPACER¤ 5.05MM | 1002- | ||
| 20Y-27-11360 | SPACER¤ 5.10MM | 1002- |
