| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | PB3135 | CARTRIDGE, EXPELLANT GAS | | |
| 2 | PB3246 | ACTUATOR, PNEUMATIC | | |
| 3 | PB3136 | BRACKET, EXPELLANT GAS | | |
| 4 | TR4731 | CAPSCREW - 5/16" - 18NC X 1" | | |
| 5 | SC4174 | LOCKWASHER - 5/16" | | |
| 6 | TD1684 | NUT - 5/16" - 18NC | | |
| 7 | EB8337 | BRACKET | | |
| 8 | PB3133 | TANK, DRY CHEMICAL | | |
| 9 | PB3828 | BRACKET, TANK | | |
| 10 | VP4693 | GROMMET | | |
| 11 | HA2568 | HOSE | | |
| 12 | VH9969 | STUD, WELD - 3/8" - 16NC X 3/4" | | |
| 13 | TC1233 | NUT - 3/8" - 16NC | | |
| 14 | TC1231 | LOCKWASHER - 3/8" | | |
| 15 | TR4439 | CAPSCREW - 1/2" - 13NC X 7/8" | | |
| 16 | VN9907 | CLAMP | | |
| 17 | DC5608 | NIPPLE, CLOSE | | |
| 18 | WB0308 | FITTING, TUBE | | |
| 19 | VA3169 | ACTUATOR, REMOTE | | |
| 20 | PB0674 | CARTRIDGE, ACTUATOR | | |
| 21 | HA0972 | HOSE | | |
| 22 | WB0397 | UNION | | |
| 23 | WB0272 | FITTING | | |
| 24 | WB0467 | ADAPTOR | | |
| 25 | HA0448 | HOSE | | |
| 26 | HA1594 | HOSE | | |
| 27 | TC6058 | CLAMP | | |
| 28 | HA5742 | HOSE | | |
| 29 | WB0266 | FITTING, TUBE | | |
| 30 | 2048889R1 | TRIM (1) | | |
| 31 | VN9908 | CLAMP | | |
| 32 | TG5720 | CAPSCREW - 3/8" - 16NC X 1" | | |
| NS|33 | | NOTE: (1) TRIM TO FIT AROUND INSIDE OF HOLE IN | | |
| NS|34 | | DECK WHERE HOSES ARE ROUTED THROUGH | | |
