| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 19M-01-12490 | BRACKET | 10035-@ | |
| 2 | 01010-81445 | BOLT | 10035-@ | |
| 3 | 01643-31445 | WASHER | 10035-@ | |
| 4 | 01010-81020 | BOLT | 10035-@ | |
| 5 | 01643-31032 | WASHER | 10035-@ | |
| 6 | (6166-11-8930) | BRACKET | 10035-@ | |
| 7 | 19M-01-12450 | BRACKET | 10035-@ | |
| 8 | 01010-81235 | BOLT | 10035-@ | |
| 9 | 01643-31232 | WASHER | 10035-@ | |
| 10 | 01010-81030 | BOLT | 10035-@ | |
| 11 | 01643-31032 | WASHER | 10035-@ | |
| 12 | 19M-01-12460 | BRACKET | 10035-@ | |
| 13 | 01010-81630 | BOLT | 10035-@ | |
| 14 | 01643-31645 | WASHER | 10035-@ | |
| 15 | 19M-01-12530 | BRACKET | 10035-@ | |
| 16 | 01010-81630 | BOLT | 10035-@ | |
| 17 | 01643-31445 | WASHER | 10035-@ | |
| 18 | 19M-01-12480 | BRACKET | 10035-@ | |
| 19 | (01010-81025) | BOLT | 10035-@ | |
| 20 | (01643-31032) | WASHER | 10035-@ | |
| 21 | 19M-06-18320 | WIRING HARNESS | 10035-@ | |
| 22 | 01010-81220 | BOLT | 10035-@ | |
| 23 | 01643-31232 | WASHER | 10035-@ | |
| 24 | 19M-01-12510 | PLATE | 10035-10041 | |
| 25 | 19M-01-12470 | PLATE | 10035-@ | |
| 26 | 19M-01-12360 | PLATE | 10035-@ | |
| 27 | 19M-01-12520 | PLATE | 10035-10041 | |
| 28 | 19M-01-12340 | PLATE | 10035-@ | |
| 29 | 19M-01-12370 | BRACKET | 10035-@ | |
| 30 | 19M-01-12380 | BRACKET | 10035-@ | |
| 31 | 19M-01-12390 | BRACKET | 10035-@ | |
| 32 | 19M-01-12410 | BRACKET | 10035-10041 | |
| 33 | 01010-81225 | BOLT | 10035-10041 | |
| 33A | 01010-81230 | BOLT | 10035-@ | |
| 34 | 01643-31232 | WASHER | 10035-10041 | |
| 35 | 19M-01-12251 | COVER | 10035-10037 | |
| 36 | 01011-81600 | BOLT | 10035-10037 | |
| 37 | 01643-31645 | WASHER | 10035-10037 | |
| 38 | 19M-06-21170 | BRACKET,(USED WHEN SUPER DOZER) | 10035-@ | |
| 39 | 01010-81225 | BOLT,(USED WHEN SUPER DOZER) | 10035-@ | |
| 40 | 01643-31232 | WASHER,(USED WHEN SUPER DOZER) | 10035-@ | |
| 41 | 08053-01512 | CLIP | 10035-@ | |
| 42 | 19M-01-12650 | RUBBER | 10038-@ | |
| 43 | 209-54-14650 | WASHER | 10038-@ | |
| 44 | 01010-81225 | BOLT | 10038-@ | |
| 45 | 01643-31232 | WASHER | 10038-@ | |
| 46 | 01010-81675 | BOLT | 10038-@ | |
| 47 | 421-70-11280 | WASHER | 10038-@ | |
| 48 | 01010-82250 | BOLT | 10038-@ | |
| 49 | 01643-32260 | WASHER | 10038-@ | |
| 50 | 01643-32780 | WASHER | 10038-@ | |
| 51 | 19M-01-12760 | RUBBER | 10035-10041 | |
| 52 | 19M-01-12540 | PLATE | 10035-@ | |
| 53 | 19M-01-12560 | PLATE | 10035-@ | |
| 54 | 19M-01-12660 | RUBBER | 10038-@ | |
| 55 | 19M-01-12720 | SHEET | 10035-10041 | |
| 56 | 19M-01-12770 | SHEET | 10035-10041 | |
| 57 | 01010-81225 | BOLT | 10035-10041 | |
| 58 | 01643-31232 | WASHER | 10035-10041 |
