| Item | Part No. | Part Name | Qty | Serial No. |
| 565-04-11700 | TANK ASS'Y,FLOAT | 702-1255 | ||
| \6\ | TANK ASS'Y,FLOAT | 510-710 | ||
| 1 | 6691-71-8811 | TANK | 702-1255 | |
| 1 | 6657-72-8810 | TANK | 510-701 | |
| 2 | 07041-13612 | PLUG | 702-1255 | |
| 2 | 07040-11409 | PLUG | 510-701 | |
| 3 | 07005-01412 | GASKET | 510-701 | |
| 3 | 07000-03032 | O-RING | 702-1255 | |
| 4 | 6610-71-8490 | ELBOW | 510-@ | |
| 5 | 02700-31206 | ELBOW | 510-@ | |
| 6 | 6684-71-8911 | BREATHER | 510-@ | |
| 7 | 565-04-11250 | TUBE | 702-@ | |
| 8 | 565-04-11241 | NIPPLE | 702-1255 | |
| 9 | 6671-71-8730 | JOINT | 510-1255 | |
| 10 | 6610-71-8820 | GASKET | 510-1255 | |
| 6610-71-8704 | VALVE ASS'Y,FLOAT | 510-1255 | ||
| 11 | 6610-71-8710 | BODY | 510-1255 | |
| 12 | 6610-71-8720 | INSERT | 510-@ | |
| 13 | 6600-01-1111 | BALL | 510-@ | |
| 14 | 04025-00312 | PIN | 510-@ | |
| 15 | 6610-71-8771 | PIN | 510-@ | |
| 16 | 6610-71-8761 | PIN | 510-@ | |
| 17 | 6610-71-8751 | GUIDE | 510-@ | |
| 18 | 6610-71-8742 | YOKE | 510-@ | |
| 19 | 02206-10404 | NUT | 510-@ | |
| 20 | 6610-71-8732 | BALL | 510-@ | |
| 21 | 01010-30616 | BOLT | 510-1255 | |
| 22 | 01602-00619 | WASHER | 510-1255 |
