| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 203-62-65421 | BRACKET | 40624-@ | |
| 2 | 01010-51030 | BOLT | 40001-44999 | |
| 3 | 01643-31032 | WASHER | 40001-@ | |
| 4 | 01010-51070 | BOLT | 40624-44999 | |
| 5 | 01643-31032 | WASHER | 40001-@ | |
| 6 | 20U-62-22280 | NIPPLE | 40001-@ | |
| 7 | 07000-02011 | O-RING | 40001-@ | |
| 8 | 20N-62-31250 | NIPPLE | 40001-@ | |
| 9 | 07000-02011 | O-RING | 40001-@ | |
| 10 | 21P-62-11590 | ELBOW | 40001-@ | |
| 11 | 07000-02011 | O-RING | 40001-@ | |
| 12 | 203-43-61510 | PEDAL | 40624-@ | |
| 13 | 01010-50820 | BOLT | 40624-44999 | |
| 14 | 01643-30823 | WASHER | 40624-@ | |
| 15 | 14X-43-12110 | PEDAL CAP | 40624-@ | |
| 16 | 203-43-61520 | SEAT | 40624-@ | |
| 17 | 01583-11408 | NUT | 40624-@ | |
| 18 | 20Y-62-25380 | PLATE | 40001-@ | |
| 19 | 01010-51030 | BOLT | 40001-44999 | |
| 20 | 01643-31032 | WASHER | 40001-@ | |
| 21 | 20Y-62-25360 | BRACKET | 40001-@ | |
| 22 | 01010-51030 | BOLT | 40001-44999 | |
| 23 | 01643-31032 | WASHER | 40001-@ |
