Item | Part No. | Part Name | Qty | Serial No. |
1 | 381-898117-2 | FLOOR | 2823-3916 | |
\0\381-898117-1 | FLOOR | 1443-2822 | ||
380-888577-1 | FLOOR | 471-1442 | ||
380-886013-1 | FLOOR | 3-470 | ||
2 | 380-S169-000 | BOLT | 2643-3916 | |
380-S168-000 | BOLT | 3-2642 | ||
2A | 380-S169-000 | BOLT | 3-3916 | |
3 | 380-WL16-000 | WASHER | 3-3916 | |
4 | 380-WF16-000 | WASHER | 3-3916 | |
5 | 380-S1812-00 | BOLT | 1443-3916 | |
380-S1612-00 | BOLT | 3-1442 | ||
6 | 380-WL18-000 | WASHER | 1443-3916 | |
380-WL16-000 | WASHER | 3-1442 | ||
7 | 380-WF18-000 | WASHER | 1443-3916 | |
380-WF16-000 | WASHER | 471-1442 | ||
380-WF16-000 | WASHER | 3-470 | ||
8 | 380-H16-0000 | NUT | 3-470 | |
9 | 381-898118-1 | RUNNER | 1443-3916 | |
380-886089-1 | RUNNER | 3-1442 | ||
10 | 380-888474-2 | FLOOR | 1443-3916 | |
\0\380-888474-1 | FLOOR | 471-1442 | ||
\0\380-174620-1 | FLOOR | 3-470 | ||
11 | 380-S169-000 | BOLT | 2643-3916 | |
380-S168-000 | BOLT | 3-2642 | ||
12 | 380-WL16-000 | WASHER | 3-3916 | |
13 | 380-WF16-000 | WASHER | 3-3916 | |
14 | 380-888585-2 | DECK | 471-3916 | |
14 | (\2\380-888585-1) | DECK | (471-1514) | |
380-186036-1 | DECK | 3-470 | ||
15 | 380-S169-000 | BOLT | 1443-3916 | |
380-S169-000 | BOLT | 3-1442 | ||
15A | 380-S1610-00 | BOLT | 3-1442 | |
16 | 380-WL16-000 | WASHER | 3-3916 | |
17 | 380-WF16-000 | WASHER | 3-3916 | |
18 | 380-890152-1 | LADDER | 1443-3916 | |
\0\380-200688-1 | LADDER | 3-1442 | ||
381-898654-1 | LADDER,(FOR BACK HOE) | 1443-3916 | ||
\0\380-887374-1 | LADDER,(FOR BACK HOE) | 281-1442 | ||
19 | 380-S1610-00 | BOLT | 3-3916 | |
20 | 380-WL16-000 | WASHER | 3-3916 | |
21 | 380-WF16-000 | WASHER | 3-3916 | |
22 | 380-H16-0000 | NUT | 3-3916 | |
23 | 380-S1811-00 | SCREW | 3-3916 | |
24 | 380-WL18-000 | WASHER | 3-3916 | |
25 | 380-H18-0000 | NUT | 3-3916 | |
26 | 380-200689-1 | RALL | 3-3916 | |
27 | 380-200690-1 | RALL | 3-3916 | |
28 | 380-S11010-0 | BOLT | 3-3916 | |
29 | 380-WL110-00 | WASHER | 3-3916 | |
30 | 380-173443-1 | SCREW | 3-3916 | |
31 | 380-885265-1 | DECAL | 3-3916 |
