| Item | Part No. | Part Name | Qty | Serial No. |
| 415-43-21103 | PEDAL ASS'Y | 12268- | ||
| 415-43-21101 | PEDAL ASS'Y | 11258-12267 | ||
| 1 | 363-43-31110 | PEDAL | 11258- | |
| 2 | 363-43-31240 | PLATE | 11258- | |
| 3 | 01435-00625 | BOLT | 11258- | |
| 4 | 415-43-21111 | BRACKET | 11258- | |
| 5 | 363-43-31250 | BOLT | 11258- | |
| 6 | 01580-10806 | NUT | 11258- | |
| 7 | 363-43-31150 | PLATE | 11258- | |
| 8 | 04205-10618 | PIN | 11258- | |
| 9 | 01641-20608 | WASHER | 11258- | |
| 10 | 04050-11612 | PIN,COTTER | 12268- | |
| 10 | 04052-10633 | PIN,SNAP | 11258-12267 | |
| 11 | 415-43-21121 | LEVER | 11258- | |
| 11 | 06600-01210 | BUSHING | 11258- | |
| 12 | 04050-13022 | PIN,COTTER | 12268- | |
| 12 | 01641-21223 | WASHER | 11258-12267 | |
| 13 | 04052-11253 | PIN,SNAP | 11258- | |
| 14 | 01010-80620 | BOLT | 12001- | |
| 15 | 01643-30623 | WASHER | 12001- | |
| 16 | 415-43-21221 | CABLE | 12001- | |
| 17 | 01580-10605 | NUT | 11258- | |
| 18 | 04256-40618 | JOINT | 11258- | |
| 19 | 04205-10618 | PIN | 11258- | |
| 20 | 01641-20608 | WASHER | 11258- | |
| 21 | 04050-11612 | PIN,COTTER | 12268- | |
| 21 | 04052-10633 | PIN,SNAP | 11258-12267 | |
| 22 | 08036-00814 | CLIP | 11258- | |
| 23 | 363-43-31170 | SPRING | 11258- | |
| 24 | 42A-16-11210 | PLATE | 12025- | |
| 25 | 04434-50810 | CLIP | 12025- | |
| 26 | 01010-81020 | BOLT | 12025- | |
| 27 | 01643-31032 | WASHER | 12025- |
