| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 206-979-7110 | HOSE ASS'Y | 11001-15000 | |
| 2 | 20Y-979-6710 | HOSE ASS'Y | 11001-15000 | |
| 3 | 11Y-09-11160 | CLIP | 11017-15000 | |
| 09480-10100 | CLAMP | 11001-11016 | ||
| 4 | 141-06-11220 | CLIP | 11001-15000 | |
| 5 | 01010-81016 | BOLT | 11001-15000 | |
| 6 | 01643-31032 | WASHER | 11001-15000 | |
| 7 | 141-06-11220 | CLIP | 11001-@ | |
| 8 | 01010-81016 | BOLT | 11001-@ | |
| 9 | 01643-31032 | WASHER | 11001-@ |
