| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 20T-54-81820 | CAP | 5001- | |
| 2 | 22M-43-21192 | CABLE | 5001- | |
| 3 | 04205-10618 | PIN | 5001- | |
| 4 | 04052-10633 | PIN,SNAP | 7744- | |
| 4 | 04052-20633 | PIN,SNAP | 5001-7743 | |
| 5 | 08034-40521 | BAND | 5001- |
- Главная
- Каталог запчастей
- Гусеничные экскаваторы
- Pc50mr 2 s/n 5001 up (for australia)
- Operator's compartment and control system
- Floor frame (heater switch cap) (canopy)
Поиск по каталогу
FLOOR FRAME (HEATER SWITCH CAP) (CANOPY)
