| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 20G-54-41320 | FLOOR MAT | H50051- | |
| 2 | 01435-40616 | BOLT | H50051- | |
| 3 | 20Y-43-41290 | COLLAR | H50051- | |
| 4 | 20Y-53-11953 | COVER | H50051- | |
| 5 | 01245-00616 | SCREW | H50051- | |
| 6 | 01643-70623 | WASHER | H50051- |
- Главная
- Каталог запчастей
- Колесные экскаваторы
- Pw148 8 s/n h50051 up
- Y0 service kit and component parts
- Floor mat two piece boom
Поиск по каталогу
FLOOR MAT- TWO-PIECE BOOM
