| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | FRAME, MAIN (1) | |||
| 2 | UPRIGHT - LH (1) | |||
| 3 | UPRIGHT - RH (1) | |||
| 4 | MM0465 | FLAT WASHER - M20 | ||
| 5 | MM0168 | CAPSCREW - M20 X 2.50 X 180 | ||
| 6 | MM0182 | NUT - M20 X 2.50 | ||
| 7 | TUBE, ROPS - LH (1) | |||
| 8 | TUBE, ROPS - RH (1) | |||
| 9 | 01643-32460 | FLAT WASHER - M24 | ||
| 10 | MM0058 | CAPSCREW - M24 X 3.00 X 60 | ||
| 11 | XB2366 | SUPPORT, DECK - RH | ||
| 12 | 01643-31645 | FLAT WASHER - M16 | ||
| 13 | MM0071 | CAPSCREW - M16 X 2.00 X 45 | ||
| 14 | XB2367 | SUPPORT, DECK - LH | ||
| 15 | XB2474 | BACKER | ||
| 16 | XB2473 | BACKER | ||
| 17 | 01643-32060 | FLAT WASHER - M20 | ||
| 18 | MM0091 | CAPSCREW - M20 X 2.50 X 80 | ||
| 19 | XB2477 | BACKER | ||
| 20 | XB2478 | BACKER | ||
| 21 | EK3336 | BACKER | ||
| 22 | EK5804 | BACKER | ||
| 23 | XB2475 | BACKER | ||
| 24 | 58B-46-00520 | SUPPORT, TROLLEY | ||
| 25 | 58B-46-00560 | PLATE - LH | ||
| 26 | 58B-46-00570 | PLATE - LH | ||
| 27 | 58B-46-00580 | PLATE - LH | ||
| 28 | 58B-46-00590 | PLATE - RH | ||
| 29 | 58B-46-00600 | PLATE - RH | ||
| 30 | 58B-46-00610 | PLATE - RH | ||
| 31 | EG4631 | SPACER | ||
| 32 | EG0963 | PAD, TAPPED | ||
| 33 | EG4406 | SPACER | ||
| 34 | EG0970 | PLATE, TAPPED | ||
| 35 | MM0093 | CAPSCREW - M16 X 2.00 X 70 | ||
| NS|36 | NOTE: (1) ORDER FROM FACTORY. |
