| Item | Part No. | Part Name | Qty | Serial No. |
| 1 | 155-54-11113 | GUARD,RADIATOR | 1063-1278 | |
| 155-54-11112 | GUARD,RADIATOR | 1003-1062 | ||
| 2 | 155-54-11520 | BOLT | 1075-@ | |
| 01050-32450 | BOLT | 1063-1074 | ||
| 01050-32450 | BOLT | 1003-1062 | ||
| 3 | 01643-02460 | WASHER | 1063-1074 | |
| 01643-02460 | WASHER | 1003-1062 | ||
| 4 | 155-54-11131 | MARK,KOMATSU | 1003-@ | |
| 5 | 01010-31025 | BOLT | 1003-@ | |
| 6 | 01602-01030 | WASHER,SPRING | 1003-@ | |
| 7 | 155-54-11144 | GRILLE,RADIATOR¤ UPPER | 1063-1278 | |
| 155-54-11143 | GRILLE,RADIATOR¤ UPPER | 1009-1062 | ||
| 155-54-11141 | GRILLE,RADIATOR¤ UPPER | 1003-1008 | ||
| 8 | 01010-31640 | BOLT | 1003-@ | |
| 9 | 01602-01648 | WASHER,SPRING | 1003-@ | |
| 10 | 01640-01626 | WASHER | 1003-@ | |
| 11 | 155-54-11154 | GRILLE,RADIATOR¤ LOWER | 1063-1278 | |
| 155-54-11153 | GRILLE,RADIATOR¤ LOWER | 1009-1062 | ||
| 155-54-11151 | GRILLE,RADIATOR¤ LOWER | 1003-1008 | ||
| 12 | 155-54-11160 | BELT | 1003-@ | |
| 13 | 01252-31680 | BOLT | 1003-@ | |
| 14 | 01602-01648 | WASHER,SPRING | 1003-@ | |
| 15 | 01640-01626 | WASHER | 1003-@ | |
| 155-54-00011 | COVER ASS'Y | 1063-1278 | ||
| 155-54-00010 | COVER ASS'Y | 1003-1062 | ||
| 16 | \6\ | COVER,RADIATOR | 1063-1278 | |
| \6\ | COVER,RADIATOR | 1003-1062 | ||
| 17 | 131-54-11150 | SPRING | 1003-@ | |
| 18 | 04050-01610 | PIN,COTTER | 1003-@ | |
| 19 | 04205-00616 | PIN,CLEVIS | 1003-@ | |
| 20 | 01010-31220 | BOLT | 1003-@ | |
| 21 | 01602-01236 | WASHER,SPRING | 1003-@ | |
| 22 | 01640-01223 | WASHER | 1003-@ | |
| 23 | 01010-31235 | BOLT | 1003-@ | |
| 24 | 155-54-11214 | BONNET | 1063-1278 | |
| 155-54-11213 | BONNET | 1003-1062 | ||
| 25 | 01010-31235 | BOLT | 1003-@ | |
| 26 | 01602-01236 | WASHER,SPRING | 1003-@ | |
| 27 | 01640-01223 | WASHER | 1003-@ | |
| 28 | 155-54-11220 | PLATE | 1003-@ | |
| 28A | 155-54-17250 | COVER | 1099-@ | |
| 29 | 01010-31225 | BOLT | 1099-@ | |
| 01010-31225 | BOLT | 1003-1098 | ||
| 30 | 01602-01236 | WASHER,SPRING | 1099-@ | |
| 01602-01236 | WASHER,SPRING | 1003-1098 | ||
| 31 | 01640-01233 | WASHER | 1099-@ | |
| 01640-01233 | WASHER | 1003-1098 | ||
| 32 | 155-54-11441 | COVER | 1003-@ | |
| 33 | 155-54-11490 | CATCH ASS'Y | 1003-@ | |
| 34 | 01010-31022 | BOLT | 1003-@ | |
| 35 | 01602-01030 | WASHER,SPRING | 1003-@ | |
| 36 | 155-54-11240 | COVER | 1003-@ | |
| 37 | 155-54-11250 | COVER,SIDE¤ L.H. | 1003-@ | |
| 38 | 155-54-11260 | COVER,SIDE¤ R.H. | 1003-@ | |
| 39 | 155-54-11270 | COVER,LOWER | 1003-1278 | |
| 40 | 01010-31022 | BOLT | 1003-@ | |
| 41 | 01602-01030 | WASHER,SPRING | 1003-@ | |
| 42 | 155-54-11282 | COVER,L.H. | 1063-@ | |
| 155-54-11281 | COVER,L.H. | 1003-1062 | ||
| 155-54-11292 | COVER,R.H. | 1063-@ | ||
| 155-54-11291 | COVER,R.H. | 1003-1062 | ||
| 43 | 135-54-11800 | CATCHER ASS'Y,L.H. FRONT AND R.H. REAR | 1003-@ | |
| 44 | 155-54-11470 | CATCH ASS'Y,L.H. REAR AND R.H. FRONT | 1003-@ | |
| 45 | 01010-31225 | BOLT | 1003-@ | |
| 46 | 01602-01236 | WASHER,SPRING | 1003-@ | |
| 47 | 01580-01210 | NUT | 1003-@ | |
| 48 | 155-54-11312 | COVER,L.H. | 1063-@ | |
| 155-54-11311 | COVER,L.H. | 1003-1062 | ||
| 155-54-11322 | COVER,R.H. | 1063-@ | ||
| 155-54-11321 | COVER,R.H. | 1003-1062 | ||
| 49 | 01010-31225 | BOLT | 1003-@ | |
| 50 | 01602-01236 | WASHER,SPRING | 1003-@ | |
| 51 | 01640-01223 | WASHER | 1003-@ | |
| 52 | 155-54-11354 | COVER | 1063-@ | |
| 155-54-11353 | COVER | 1021-1062 | ||
| 155-54-11352 | COVER | 1003-1020 | ||
| 53 | 01010-31225 | BOLT | 1003-@ | |
| 54 | 01602-01236 | WASHER,SPRING | 1003-@ | |
| 55 | 01640-01223 | WASHER | 1003-@ | |
| 56 | 155-54-11431 | BRACKET | 1063-@ | |
| 155-54-11430 | BRACKET | 1003-1062 | ||
| 57 | 01010-31225 | BOLT | 1003-@ | |
| 58 | 01602-01236 | WASHER,SPRING | 1003-@ | |
| 59 | 01640-01223 | WASHER | 1003-@ | |
| 60 | 155-54-11364 | COVER,INSTRUMENT PANEL | 1021-@ | |
| 155-54-11363 | COVER,INSTRUMENT PANEL | 1003-1020 | ||
| 61 | 155-54-11411 | STRIP | 1003-@ | |
| 62 | 01010-31225 | BOLT | 1003-@ | |
| 63 | 01010-31240 | BOLT | 1003-@ | |
| 64 | 01602-01236 | WASHER,SPRING | 1003-@ | |
| 65 | 01643-01232 | WASHER | 1003-@ | |
| 66 | 155-54-11460 | PLATE | 1003-@ | |
| 67 | 155-54-11422 | FRAME | 1003-@ | |
| 68 | 01010-31230 | BOLT | 1003-@ | |
| 68A | 01010-31235 | BOLT | 1003-@ | |
| 69 | 01602-01236 | WASHER,SPRING | 1003-@ | |
| 70 | 01643-01232 | WASHER | 1003-@ | |
| 71 | 155-54-11371 | HANDLE | 1003-@ | |
| 72 | 07283-02738 | CLIP | 1003-@ | |
| 73 | 01643-01032 | WASHER | 1003-@ | |
| 74 | 01598-01011 | NUT | 1003-@ | |
| 75 | 01010-31235 | BOLT | 1027-@ | |
| 01010-31235 | BOLT | 1003-1026 | ||
| 76 | 01602-01236 | WASHER,SPRING | 1027-@ | |
| 01602-01236 | WASHER,SPRING | 1003-1026 | ||
| 77 | 01640-01223 | WASHER | 1027-@ | |
| 01640-01223 | WASHER | 1003-1026 | ||
| 78 | 155-54-11510 | COVER | 1021-@ | |
| 79 | 01010-31225 | BOLT | 1021-@ | |
| 80 | 01602-01236 | WASHER,SPRING | 1021-@ |
